Thailand Middle East Wire And Cable Extruder Machine , Wire Making Machine
Thailand Middle East Wire And Cable Extruder Machine , Wire Making Machine
Thailand Middle East Wire And Cable Extruder Machine , Wire Making Machine
Thailand Middle East Wire And Cable Extruder Machine , Wire Making Machine
Thailand Middle East Wire And Cable Extruder Machine , Wire Making Machine
Thailand Middle East Wire And Cable Extruder Machine , Wire Making Machine
Specifications
Brand Name :
HOOHA
Model Number :
HH-35/45/50/70/80/90/100/110/120/150/180
Certification :
CE ISO
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10pcs/month
Delivery Time :
25 working days
Packaging Details :
Plastic PE foam
Motor :
Siemens
Inveter :
YASKAWA
speed :
300-400m/min
Power :
50KW/H
Voltage :
380V or customized
Direction :
left or right
weight :
15 ton
Material :
PVC/PE
HS Code :
8479400000
Description

Wire extrusion machine Thailand , Middle East wire and cable extrusion machinery

1. Professional and Strong Manufacture and Sells team

Team of HOOHA service 　 　 　 　 　
Name education Position Mainly responsible for project Specializing in project Industry working history ( year )
zanyang Xie college General Engineer The total project design and planning power cable 15
xioahua Hu college Vis general engineer The total project design and planning Comunication cable 10
Chnaghong Cheng college Engineer Drawings and after-sales service Teflon,Optical fiber cable machine 25
xiuwu Chen college General Engineer The total project design and planning copper drawing machine 15
lixin Yuan college Engineer The project design and planning coppwer wire making technical 16
zhenghai Qiu college cable engineer After service cable making and cable factory management servie 15
jinxin Liu college Marketing engineer After service electrical engineer 7
xingguo Tang High school Electrical engineer After service electrical engineer 10
changqiang Li High school Maintain engineer After service machina maintain and install service 10
haipin Li University Engineering director Marketing and sales project consulting 8
sen Yang University Engineering translator Marketing and sales project consulting 5
Chitiezhong University Engineering translator Project engineer project consulting 8
Hexueqing University Engineering translator Project assistance project consulting 2
fengmin University Engineering translator Project assistance project consulting 2
Cable Test and fireproofing material test machine project
Suming University fireproofing materialtest machine engineer fireproofing materialtest machine project manager 12
Denxinda University Cable Test machine engineer Cable Test machine engineer project manager 10
lixianwen High school Electrical engineer After service machine install and manufacture 8
zhangdayou High school System engineer After service machine install and manufacture 6
Lutianhai High school Electrical engineer After service machine install and manufacture 4

Thailand Middle East Wire And Cable Extruder Machine , Wire Making Machine

Thailand Middle East Wire And Cable Extruder Machine , Wire Making Machine

Thailand Middle East Wire And Cable Extruder Machine , Wire Making Machine

​
2.HOOHA Spare Parts Brands:
Motor: Dongguan Motor , Teco, ABB, Siemens
Inverter : Japan Yaskawa, Siemens, Taiwan Teco
Temperature Control Meter: Japan RKC
Auxiliary Relay: Japan Omron
Ammeter and Voltmeter: Taiwan Risesun
Indicator, Switch and Button: Taiwan TEND
Contactor: Taiwan Shihlin
Line Speed Meter: Taiwan FOTEK/Yangming
Bearing : NSK, SKF


3.Technical Parameters

HOOHA Coaxial wire manufacturing machine
Model HOOHA 45+30 HOOHA 65+35 HOOHA 90+40
Spec
Pay off Motorized pay off Motorized pay off Motorized pay off
Pay off bobbin PN300-500 PN400-630 PN500-630
Screw diameter 45+30(sub-extruder) 65+35( sub-extruder ) 90+40( sub-extruder )
Screw L: D 36:01:00 36:01:00 36:01:00
Capacity (kg/hr) 25 80 170
Main motor 15 HP 30 HP 50HP
Wire diameter Φ0.8-2.5 Φ3.5-6.0 Φ8.0-15.0
Temp control 8zone 10 zone 12zone
Cooling device U type single layer(18m) U type single layer(30m) U type single layer(40m)
Pulling power 3HP 5HP 10HP
Accumulator horizontal horizontal horizontal
Length of accumulating 200m 200m 200m
Running speed MAX300 MAX300 MAX300
Taking up type Double bobbin Double bobbin Double bobbin
Taking up bobbin PN400-500 PN500-800 PN630-1000
Electricity control Inverter +PLC(for elected) Inverter +PLC(for elected) Inverter +PLC(for elected)

4.Line data:

1. Process material: PE/foaming PE

2. Max. Foaming degree: 70 %

3. Insulated cable size: 8.0mm

4. Line speed: SFS physical foam insulated wire should be 50---250m/min (based on exact cable size)

5. Power: 3P/ 380V / 50Hz

6. Height of cable passage over floor: 1000mm

7. Machine color: Blue

8. Machine direction: from right to left

9. Total length: about 40m


5.Afetr service


1).Delivery dates: 45 days
2).Payment: TT or L/C
3).Packing: Wood packing and PE plastic packing ensure the goods safety on the transportation.
4). Install and training service: 2 professional engineers who has over 5 years overseas install and cable manufacture training experience.
5) after service phone number online



6.Contact information
Phone: +8613763134250
Http//:www.hoohahk.com
Add:Huifu industry park,Houhu road No38. Humen Town,
Dongguan City, Guangdong Province,China


7.Where are we:
Hongkong airport to Humen by boat 2 hours
Guangzhou airport to Humen by car 2 hours
Shenzhen airport to Humen by car 1 hour
Guangzhou South high speed train station to Humen 20 minutes
Shenzhen North high speed train station to Humen 20 minutes
