Specifications
Brand Name :
HOOHA
Model Number :
80+35
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5 units per month
Delivery Time :
25 working days
Packaging Details :
PE foam ,wooden package
copper wire :
1.5,2.5,4,6,10 ,16mm2
material :
PVC,PE
application :
signal, power cord,power cable
market :
India
electricity brand :
Siemens
technical support :
yes
workers for the production line :
2
machine weight :
4500 KG
technician :
TEAM for you
line speed :
150m/min-400 m/min
Description

Wire And Cable Machinery Single Core 1mm2-16mm2 Cable Manufacturing Machine

Single core 1mm2-16mm2 cable manufacturing machine for power cable ,building cable

Process of single core cable (solid copper ) 1mm2-16mm2

1.8mm copper bar -- wire drawing to suitable size ( RBD wire drawing machine )

2. 80+35 extrusion machine ---- insulation

1. 8mm copper bar -- wire drawing to suitable size (RBD wire drawing machine)

No. Name Qty./Unit Note
1 Pay off Stand 1set
2 DL400-13 Drawing Machine 1set
3 TH5000 Annealer 1set
4 YG400 Joy Tension Rod 1set
5 SN630-2 Take up 1set
6 Operation Panel 1set
7 Electrical Control System 1set
8 Pointing Machine 1set
9 Welding Machine 1 set

Single Core 1mm2 - 16mm2 Building Cable Manufacturing Machine Siemens Electricity

2. 80+35 extrusion machine

Machine technical feature

1.Concentricity: 93-97% OD tolerance: Solid +/-0.005
2.Wire specification: Φ1.5mm-12mm
3.The highest output: 140KG/hr The highest wire speed: 400M/MIN
4.Body temperature will be controlled within ±1ºC
5.Extrusion material: PVC, SR-PVC, PE, PP, PU etc.
6.Screw parameters:L/D ratio:26;1,compression ratio:2.7-3.2,screw material:

38CrMoAIA,vacuum heating treatment,surface grinding polishing chromium plating.

Machine parts

No. Parts name&Specs. Qty
1 ø500-630mm motorized pay off stand 1set
2 dancer 1set
3 80+35 mm extruder 1set
4 PLC SIEMENS Electrical control cabinet 1set
5 Hopper dryer feeding machine 1set
6 1.5M movable cooling water tank 1set
7 Laser diameter tester (Eectrl) 1set
8 7.5M single layer cooling water tank 1set
9 10M high precision horizontal wire accumulator 1set
10 ø570mm dual-wheels capstan 1set
11 High frequency spark tester 1set
12 ø500-630mm dual-axis take up 1set
13 1246 automatic packing and wrapping machine

1 set

Single Core 1mm2 - 16mm2 Building Cable Manufacturing Machine Siemens Electricity

Main parts brand
1.Motor: Siemens
2.Frequency converter: Yaskawa
3.Bearing: NSK (Japan brand)
4.Electrical component: Siemens or Omron
5.PLC controller: Siemens



Our Service
Pre-Sales Service After-Sales Service
* Inquiry and consulting support. * Training how to install and how to use the machine
* Customized design support. * Engineers available to service machinery overseas.

1.did you want but feel difficult to invest a cable plants ?

2.did you feel that it is too long to payback what you invest ?

3.did you feel that the project take too long time and not finish since lacking and difficult to get locally ?

4.did you feel that there is much waste during the project working since the not good plant from the beginning ?

if our experiences and technical can help you , please free to contact with us
