Specifications
Brand Name :
HOOHA
Model Number :
HOOHA-drawing
Certification :
CE ISO
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20 sets/month
Delivery Time :
35 working days
Packaging Details :
plastic or wooden packing
Usage :
drawing
Max. Number of Block :
21
Wire Size :
0.95-1.65mm
Wire Finished Diameter :
0.15-0.4mm
Max Wire Speed :
2000m/Min
Spool Bobbin Size :
300*215*270mm
Max Loading Capacity :
50kg
Inveter :
YASKAWA
Dimensions :
3*2.5*2.3m
Specification: :
CE ISO SGS
HS Code :
8463102000
Description

Copper Small Fine Wire Drawing Machine With Annealing Machine , High Speed

1.Professional and Strong Manufacture and Sells Team

Team of HOOHA service
Name education Position Mainly responsible for project Specializing in project Industry working history ( year )
zanyang Xie college General Engineer The total project design and planning power cable machine 15
xioahua Hu college Vis general engineer The total project design and planning net cable,data cable machine 10
Chnaghong Cheng college Engineer Drawings and after-sales service Teflon,Optical fiber cable machine 25
xiuwu Chen college General Engineer The total project design and planning copper drawing machine 15
lixin Yuan college Engineer The project design and planning coppwer wire making technical 16
zhenghai Qiu college cable engineer After service cable making and cable factory management servie 15
jinxin Liu college Marketing engineer After service electrical engineer 7
xingguo Tang High school Electrical engineer After service electrical engineer 10
changqiang Li High school Maintain engineer After service machina maintain and install service 10
haipin Li University Engineering director Marketing and sales project consulting 10
sen Yang University Engineering translator Marketing and sales project consulting 7


Copper Small Fine Wire Drawing Machine With Annealing Machine , High SpeedCopper Small Fine Wire Drawing Machine With Annealing Machine , High Speed

2, Drawing machine specifications

wire drawing machine with annealing
Model 17DHT SMD205T 24DHT
control system digital readout button
power control dual inverter
wire inlet diameter 0.75-1.6mm 0.95-1.65mm 0.5-1.2mm
wire finished diameter 0.2-0.5mm 0.15-0.4mm 0.1-0.32mm
max wire speed 2000m/min 2000m/min 2000m/min
max dies NO. 17(18) 24 24
mechanical elongation 15%+8.7% 15%+13% 13%+8.7%
construction of the machine boday casting+steel plate welded and annealed
drawing capastan ceramic coated
capastan diameter 242mm 242mm 242mm
fix speed capastan diameter 206mm
drawing/take up motor AC55kw/AC11kw
spool bobbin size 300*215*270mm
transmission type import advanced flat belt drive
bobbin loading unloading type expansion shaft or single sfaft cone
main motor 15kw 15kw 11kw
spooler motor 4kw
tension adjustment weight type tension pulley
fix system automatic control of take up by PID
max loading capacity 50kg
lubrication capacity 50L/min
lubrication type spraying
brake magnetic brake
lubrication type for bearing without oil
annealing control 3 poles DC current output
annealing capacity 30 KVA 21 or 30 KVA 21KVA
annealing voltage 0-57V
annealing current 400A 400A 300A
total power 19kw+30KVA 19kw+30KVA 15kw+30KVA
power source 380V,50/60HZ
Steam consumption 6-9kg/h 0.2-0.3MPa
coiling water consumption 4-8m³/h 0.2-0.25MPa
air consumption 15-25m³/h 0.4-0.6Mpa
dimensions 3*2.5*2.3M
weight 3000kg




3. Spare Parts Brands:


Motor: Dongguan Motor , Teco, ABB, Siemens
Inverter : Japan Yaskawa, Siemens, Taiwan Teco
Temperature Control Meter: Japan RKC;
Auxiliary Relay: Japan Omron ;
Ammeter and Voltmeter: Taiwan Risesun ;
Indicator, Switch and Button: Taiwan TEND ;
Contactor: Taiwan Shihlin
Line Speed Meter: Taiwan FOTEK/Yangming
Bearing : NSK, SKF

4.Afetr service


1).Delivery dates: 45 days
2).Payment: TT or L/C
3).Packing: Wood packing and PE plastic packing ensure the goods safety on the transportation.
4). Install and training service:

professional engineers who has over 10 years overseas install and cable manufacture training experience.
