High Efficiency Cable Stranding Machine / Copper Or Aluminum Wire Tubular Stranding Machine
High Efficiency Cable Stranding Machine / Copper Or Aluminum Wire Tubular Stranding Machine
High Efficiency Cable Stranding Machine / Copper Or Aluminum Wire Tubular Stranding Machine
High Efficiency Cable Stranding Machine / Copper Or Aluminum Wire Tubular Stranding Machine
High Efficiency Cable Stranding Machine / Copper Or Aluminum Wire Tubular Stranding Machine
High Efficiency Cable Stranding Machine / Copper Or Aluminum Wire Tubular Stranding Machine
High Efficiency Cable Stranding Machine / Copper Or Aluminum Wire Tubular Stranding Machine
High Efficiency Cable Stranding Machine / Copper Or Aluminum Wire Tubular Stranding Machine
Specifications
Brand Name :
HOOHA
Model Number :
630
Certification :
SGS/ CE/ ISO
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5 sets/ month
Delivery Time :
45 working days
Packaging Details :
Plastic packing
model :
630
copper diameter :
1.0mm-4.5mm
aluminum diameter :
1.5mm-5.0mm
steel wire diameter :
1.5mm -3.5mm
OD :
15mm
Technician Team :
20 years senior engineer on wire and cable
Market :
UZ , Algeria , Russia , Indonesia etc
factory :
since 2003
Description

Copper Wire , Aluminum Wire Tubular Stranding Machine, High Speed Capacity

It is for 1+6+12+18+24+37 etc strands copper wire , aluminum wire , ACSR conductor to round

Technical Parameter:

Model Main Specification
CLK400
CLK500
CLK630
Single Wire Diameter
1.2mm-5mm
1.2mm-5mm
1.2mm-5mm
Max After Stranding Diameter
50mm
50mm
50mm
RPM
57-157r/min
65-143r/min
50-125r/min
Stranding Pitch
71-971mm
58-978mm
67-1272mm
Max Line speed
55.35m/min
63.63m/min
63.63m/min
Pay Off Drum Size In Cage
PN400mm
PN500mm
PN630mm
Central Pay Off Drum Diameter
PN800-1600mm
PN800-1600mm
PN800-1600mm
Take Up Drum Diameter
PN1000-2000mm
PN1000-2000mm
PN1000-2000mm

High Efficiency Cable Stranding Machine / Copper Or Aluminum Wire Tubular Stranding MachineHigh Efficiency Cable Stranding Machine / Copper Or Aluminum Wire Tubular Stranding Machine
