1000mm High and Low Temperature Tensile Testing Machine For Wire 200KN
1000mm High and Low Temperature Tensile Testing Machine For Wire 200KN
1000mm High and Low Temperature Tensile Testing Machine For Wire 200KN
1000mm High and Low Temperature Tensile Testing Machine For Wire 200KN
1000mm High and Low Temperature Tensile Testing Machine For Wire 200KN
1000mm High and Low Temperature Tensile Testing Machine For Wire 200KN
1000mm High and Low Temperature Tensile Testing Machine For Wire 200KN
1000mm High and Low Temperature Tensile Testing Machine For Wire 200KN
Specifications
Brand Name :
YUYANG
Model Number :
YYL-008
Certification :
GB, ISO, JIS, ASTM, DIN
Place of Origin :
China
Supply Ability :
50 Piece/Pieces per Month
Delivery Time :
15-20 work days
Packaging Details :
Wooden Case
Walking space: :
1000mm
Force resolution: :
1/100000~1/1000000
Force accuracy: :
≤0.5%
Power magnifying multiples: :
seven segment
Displacement resolution: :
1/1000
Large deformation extensometer: :
±1mm
Power supply: :
220V 50HZ (110V as required)
Test Width: :
400mm (special test width customized)
Temperature accuracy :
0.3%
Temperature uniformity :
±2°C
Description

1000mm High and Low Temperature Tensile Test Machine For Wire 200KN

Product introduction:

Completion-aided test devices of the high and low temperature tensile test machine: special high and low temperature box (temperature humidity chamber), temperature-protected sensor, high low temperature fixtures, sliding auxiliar.Two cooling options for highlow temperature box: electronic cooling and liquid- nitrogen refrigerating.Application in 200KN-below mechanical material tests under high and low temperature: stretching, peeling, tearing, compression, bending, shearing, piercing, low cycle fatigue. Mainly used in metal, plastic, rubber, textiles, synthetic chemicals, wire and cable, leather etc.

Temperature range:

1. Temperature range:-70~+150℃ when equipped with high and low temperature chamber;

2. Temperature range: normal temperature ~1000℃ when equipped with high-temperature furnace.

Parameters:

1. Load:1, 5, 10, 20, 50, 100, 200, 500, 1000, 2000, 5000, 10000, 20000Kg

2. Force resolution:1/100000~1/1000000

3. Force accuracy:≤0.5%

4. Power magnifying multiples:seven segment

5. Displacement resolution:1/1000

6. Displacement accuracy:≤0.3%

Power units : Kg, N, KN, g, lb; displacement unit: mm, cm, inch

7. Metal extensometer resolution: 1/1000

8. Metal extensometer accuracy: ≤0.5%

9. Large deformation extensometer: ±1mm

10. Speed range: 0.001mm / min ~ 1000mm / min (special speed testing customized)

11. Walking space: 1000mm (Holder excluded,special test space customized )

12. Test Width: 400mm (special test width customized)

13. Power supply:220V 50HZ (110V as required)

14. Machine Size: about 500 × 500 × 1800 mm (L × W × H)

15. Machine weight: 250~800KG

Model YYL-008-300 YYL-008-30/300G YYL-008-60/300G
Temperature control range Room temperature ~ +300°C +300°C~-30°C +300°C~-60°C
Inside size 500*500*1800 (for electronic universal testing machine whose pillar span is 400mm and above)
Model of control temperature PID automatic temperature control
Temperature accuracy 0.3%
Temperature fluctuation range ±0.5°C
Temperature uniformity ±2°C
Manner of heating Magnesium powder heating tube
Manner of refrigeration / single compressor or liquid nitrogen double compressors or liquid nitrogen
View window of hollow heating glass Yes Yes Yes
Working power 380V 50Hz 1kW 380V 50Hz 2kW 380V 50Hz 3kW

Standards:

GB, ISO, JIS, ASTM, DIN

1000mm High and Low Temperature Tensile Testing Machine For Wire 200KN1000mm High and Low Temperature Tensile Testing Machine For Wire 200KN1000mm High and Low Temperature Tensile Testing Machine For Wire 200KN
