4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines
4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines
4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines
4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines
4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines
4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines
4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines
4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines
Specifications
Brand Name :
YUYANG
Model Number :
YY824
Certification :
GB/T4802.1-2008, DIN 53863.2
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
10 sets per month
Delivery Time :
5-10 work days
Packaging Details :
Plywood Box
Product Name :
Textile Testing Equipment
Usage :
Martindale Abrasion Test
Specimen size :
112.8mm with area 100cm2
Rubbing times :
1~9999S
Rubbing speed :
60 RPM
Power supply :
AC220V 50Hz 60W
Weight :
35Kg
Dimensions :
540*250*345 mm (L*W*H)
Description

4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Equipment

Description:

1. This tester can check the abrasion and pilling capability for various textile products rubber and outside layer, lining or underlayer of the footwear or the similar fabric.

2. Using area: Martindale abrasion and pilling tester to test the abrasion of of the lining, textiles and shoes leather

Features:


1. Driven by synchronous motor, less maintenance
2. Provided different pressing weight with 490cN, 590cN and 780cN
3. Rubbing times is presettable and duly displayed on LED panel.
4. Stop automatically after reaching preset rubbing times.
5. Rubbing times can be accumulated when testing
6. Two working mode, rubbing times increase from 1 or decrease from preset times
7. The effective length of brush adjustable to control rebbing effects

Standard:

GB/T4802.1-2008, DIN 53863.2

Specifications:

1. Pilling trajectory: circular track of 40mm diameter

2. Brush with adjustable height: 2~12mm

3. Pressure for specimen:

Chemical Fiber fabric: 590cN

Combed wool fabric:780cN

Crude wool fabric 490cN

4. Specimen size: 112.8mm with area 100cm2

5. Rubbing times: 1~9999S

6. Rubbing speed: 60 RPM

7. Power: AC220V 50Hz 60W

8. Dimension: 540*250*345 mm (L*W*H)

9. Weight: 35KG

10. Accessories: power line 1pcs

4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines
