Fire Wafer Type Worm Gear Butterfly Valve Grey Iron Wear Resistant
Fire Wafer Type Worm Gear Butterfly Valve Grey Iron Wear Resistant
Specifications
Brand Name :
Y
Model Number :
D371X-16Q
Place of Origin :
China
MOQ :
10 pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000 pcs per year
Delivery Time :
5-8 work days
Packaging Details :
wooden box 1200*1100*1100
product name :
Fire Protection Valves
Body material :
Grey Iron/Ductile Iron
power :
worm
temperature :
≤80℃
working pressure :
1.0~1.6mpa
color :
Red
connection :
wafer
medium :
water
Description

Fire Worm Gear Wafer Butterfly Valve 1.6mpa Pressure Water Fire Protection Valves

characteristic

The valve adopts double eccentric structure, which has the sealing function of closing and tightening, and the sealing performance is reliable. The sealing pair is made of stainless steel and nitrile oil resistant rubber, with long service life. The rubber sealing ring can be located on the valve body or on the butterfly plate. It can be suitable for media with different characteristics for users to choose. The butterfly plate adopts frame structure with high strength, large overflow area and small flow resistance. The integral baking paint can effectively prevent corrosion, and can be used in different media as long as the sealing material of the sealing valve seat is replaced. The valve has a two-way sealing function. It can be installed in any direction without being controlled by the medium flow direction or affected by the spatial position. The valve has unique structure, flexible operation, labor-saving and square

Introduction

The worm gear soft sealing center line wafer butterfly valve and double eccentric flange butterfly valve have compact structure, easy 90 ° rotary switch, reliable sealing and long service life. They are widely used for water supply and drainage in water plants, power plants, steel mills, papermaking, chemical industry, catering and other systems as regulation and cut-off.

Dimension

DN ф H B Z-фd L
DN50 (2" ) 125 200 220 4-ф18 43
DN65 (2.5" ) 145 220 220 4-ф18 46
DN80 (3") 160 230 220 4-ф18 46
DN100 (4" ) 180 240 220 4-ф18 52
DN125 (5") 210 250 268 4-ф18 56
DN150 (6") 240 265 268 4-ф23 56
DN200 (8") 295 310 289 4-ф23 60
DN250 (10" ) 355 340 289 4-ф25 68
DN300 (12" ) 410 380 289 4-ф30 78
DN35O (14" ) 470 420 289 4-ф30 78
DN400 (16" ) 515 522 363 4-ф31 88
DN450 (18") 565 536 363 4-ф31 106
DN500 (20" ) 620 604 363 4-ф31 132
DN600 ( 24") 725 695 427 4-ф34 154
DN700 840 811 482 4-M27 165
DN800 952 893 482 4-M30 190
DN900 1050 903 529 4-M30 211
DN1000 1160 983 529 4-M33 224
