AISI 304 MSS SP-114 90DEG CL1000 Stainless Steel Cast Socket-Welding 90 Degree Elbow
AISI 304 MSS SP-114 90DEG CL1000 Stainless Steel Cast Socket-Welding 90 Degree Elbow
Specifications
Brand Name :
KASUGAI
Model Number :
304 SP-114 90DEG CL1000 Cast Socket-Welding Elbow
Certification :
ISO-9001; PED; AD 2000
Place of Origin :
CHINA
MOQ :
TO BE NEGOTIATED
Price :
PER BASE MATERIAL PRICE
Payment Terms :
L / C , T / T
Supply Ability :
100 TONS / MONTH
Delivery Time :
60 DAYS FOR ONE CONTAINER
Packaging Details :
SEAWORTHY PACKING
Product Name :
AISI 304 MSS SP-114 90DEG CL1000 3/4” Stainless Steel Cast Socket-Welding 90 Degree Elbow
Size Range :
1/8" to 2"
Fitting Type :
Socket-Welding 90o Elbow
Pressure Class :
Class 1000 NPT
Standards :
AISI 304/L
Dimensions :
MSS SP-114-2018
Description

AISI 304 MSS SP-114 90DEG CL1000 Stainless Steel Cast Socket-Welding 90 Degree Elbow

Product Information

A Socket Weld Alloy Steel Flange is a specific type of flange used in piping systems for various industrial applications, particularly in high-pressure and high-temperature environments where corrosion resistance and strength are crucial.

Socket Weld Fittings: Fittings that are inserted into the pipe and then welded around the joint for a strong connection.

Product Name AISI 304 MSS SP-114 90DEG CL1000 Stainless Steel Cast Socket-Welding 90 Degree Elbow
Fitting Type Socket-Welding 90o Elbow
Dimensions MSS SP-114:2018
Size Range 1/8” to 2"
Pressure Class Class 1000
Materials AISI 304/L

Standard & Materials:AISI 304/L

SAE/ANSI 304 (AISI 304) is a widely used stainless steel grade that is part of the 300 series of austenitic stainless steels.

· SAE 304 stainless steel typically contains around 18% chromium and 8% nickel, making it a versatile and commonly used stainless steel grade.

· SAE 304 offers good corrosion resistance in various environments, making it suitable for a wide range of applications, including those involving exposure to moisture and some chemicals.

AISI 304/L Chemical Composition (%)

Grade C, max Cr Mn, max Ni P, max S, max Si, max
AISI 304 0.08 18~20 2 8~10.5 0.045 0.03 1
AISI 304L 0.03 18~20 2 8~12 0.045 0.03 1

AISI 304/L Mechanical Properties

Mechanical Properties 304 304L
Hardness, Knoop 138 158
Hardness, Rockwell B 70 82
Hardness, Vickers 129 159
Tensile Strength, Ultimate 505 MPa 564 MPa
Tensile Strength, Yield 215 MPa 210 MPa
Elongation at Break 70% 58%
Modulus of Elasticity 193~200 GPa 193~200 GPa
Charpy Impact 325 J 216J

SP-114 Dimensions of Class 1000 Wrought Socket-Welding Fittings (in inches)

AISI 304 MSS SP-114 90DEG CL1000 Stainless Steel Cast Socket-Welding 90 Degree Elbow

NPS Center-to-End Elbows, Tees & Crosses Center-to-End 45o Elbows Socket Bore (min.)/(max.)

Bore Dia.

(min.)/(max.)

 Socket Depth (min.) Metal Thickness Outside Band Dia. (min.) Full Coupling Length (min.) Cap Height (min.) Flat Top Cap Thickness (min.)
A C SB BD SD G H1 W P G1
⅛ 0.81 0.69 0.420/0.440 0.227/0.337 0.32 0.09 0.55 1.00 0.68 0.09
¼ 0.81 0.69 0.555/0.575 0.380/0.440 0.32 0.09 0.74 1.00 0.68 0.09
⅜ 0.93 0.81 0.690/0.710 0.515/0.575 0.32 0.10 0.86 1.12 0.81 0.10
½ 1.12 0.87 0.855/0.875 0.644/0.704 0.32 0.10 1.05 1.38 0.93 0.12
¾ 1.31 1.00 1.065/1.085 0.854/0.914 0.37 0.12 1.30 1.50 1.06 0.13
1 1.330/1.350 1.067/1.127 0.44 0.13 1.61 1.62 1.31 0.15
1¼ 1.675/1.695 1.412/1.472 0.50 0.14 1.86 2.00 1.62 0.17
1½ 1.915/1.935 1.652/1.712 0.50 0.15 2.17 2.12 1.62 0.19
2 2.406/2.426 2.127/2.187 0.56 0.17 2.74 2.50 1.75 0.22
