P6KE68A 600 Watts Transient Voltage Suppressor double diode model
P6KE68A 600 Watts Transient Voltage Suppressor double diode model
P6KE68A 600 Watts Transient Voltage Suppressor double diode model
P6KE68A 600 Watts Transient Voltage Suppressor double diode model
P6KE68A 600 Watts Transient Voltage Suppressor double diode model
P6KE68A 600 Watts Transient Voltage Suppressor double diode model
Specifications
Brand Name :
TSC
Model Number :
P6KE68A
Certification :
Original Factory Pack
Place of Origin :
Original
MOQ :
50pcs
Price :
negotiation
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
5200PCS
Delivery Time :
1 day
Packaging Details :
please contact me for details
Description :
92V Clamp 6.6A Ipp Tvs Diode Through Hole DO-204AC (DO-15)
PPK :
600 Watts
PD :
5 Watts
IFSM :
100 Amps
VF :
3.5 / 5.0 Volts
RθJL :
10 ℃/W
Description

P6KE68A

600 Watts Transient Voltage Suppressor double diode model

Features

UL Recognized File # E-326243

Qualified as per AEC-Q101

Plastic package has Underwriters Laboratory Flammability Classification 94V-0

600 watts surge capability at 10 / 1000 us waveform

Excellent clamping capability

Low Dynamic impedance

Fast response time: Typically less than 1.0ps from 0 volt to VBR for unidirectional and 5.0ns for bidirectional

Typical IR less than 1uA above 10V

High temperature soldering guaranteed: 260℃ / 10 seconds / .375",(9.5mm) lead leCM GROUPh / 5lbs., (2.3kg) tension

Green compound with suffix "G" on packing code & prefix "G" on datecode

Mechanical Data

Case: Molded plastic

Lead: Pure tin plated lead free, solderable per MIL-STD-202, Method 208

Polarity: Color band denotes cathode except bipolar

Weight: 0.42 gram
