SN74LVC125ADBR Programmable Logic ICS Buffers & Line Drivers Tri-State Quad Bus

1 Features

• 3-State Outputs

• Separate OE for all 4 buffers

• Operates From 1.65 V to 3.6 V

• Specified From –40°C to 85°C and –40°C to 125°C

• Inputs Accept Voltages to 5.5 V

• Maxt of4.8nsat3.3V pd

• Typical VOLP (Output Ground Bounce) <0.8VatVCC =3.3V,TA =25°C

• Typical VOHV (Output VOH Undershoot) >2VatVCC =3.3V,TA =25°C

• Latch-Up Performance Exceeds 250 mA Per JESD 17

• ESD Protection Exceeds JESD 22

  • – 2000-V Human-Body Model

  • – 200-V Machine Model

  • – 1000-V Charged-Device Model


2 Applications

• Cable Modem Termination Systems

• IP Phones: Wired and Wireless

• Optical Modules

• Optical Networking:

– EPON or Video Over Fiber

• Point-to-Point Microwave Backhaul

• Power: Telecom DC/DC Modules:

– Analog or Digital

• Private Branch Exchanges (PBX)

• TETRA Base Stations

• Telecom Base Band Units

• Telecom Shelters:

  • – Filter Unit s

  • – Power Distribution Units (PDU)

  • – Power Monitoring Units (PMU)

  • – Wireless Battery Monitoring

  • – Remote Electrical Tilt Units (RET)

  • – Remote Radio Units (RRU)

  • – Tower Mounted Amplifiers (TMA)

• Vector Signal Analyzers and Generators

• Video Conferencing: IP-Based HD

• WiMAX and Wireless Infrastructure Equipment

• Wireless Communications Testers

• xDSL Modems and DSLAM 1

This quadruple bus buffer gate is designed for 1.65-V to 3.6-V VCC operation.
The SN74LVC125A device features independent line drivers with 3-state outputs. Each output is disabled when the associated output-enable (OE) input is high.
To ensure the high-impedance state during power up or power down, OE should be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.
Inputs can be driven from either 3.3-V or 5-V devices. This feature allows the use of this device as a translator in a mixed 3.3-V/5-V system environment.
Device Information
