LM3409MY PFET Buck Controller For High Power LED Driver
LM3409MY PFET Buck Controller For High Power LED Driver
Specifications
Model Number :
LM3409MY
MOQ :
10 pcs
Price :
Bargain
Payment Terms :
T/T
Supply Ability :
1kk/months
Delivery Time :
1-5 days
Packaging Details :
Carton
Description :
LED Driver IC 1 Output DC DC Controller Step-Down (Buck) Analog, PWM Dimming 10-HVSSOP
Product Category :
LED Lighting Drivers
Minimum Operating Temperature :
- 40 C
Maximum Operating Temperature :
+ 125 C
Product :
PFET Buck Controllers
Subcategory :
Driver ICs
BOM sevice :
Welcome
Description

LM3409MY LM3409 Driver ICs LM4811MM LM5060MM LM3481MM LM5020MM LM3445MM LM5106MM LM25011

LM3409,LM3409-Q1,LM3409HV,LM3409HV-Q1

LM3409,-Q1, LM3409HV,-Q1 P-FETBuck Controllerfor High-PowerLED Drivers

Features

• LM3409-Q1 and LM3409HV-Q1 are Automotive Grade Products: AEC-Q100 Grade1 Qualified

• 2-Ω, 1-A Peak MOSFET Gate Drive

• VIN Range:6 V to 42 V (LM3409,LM3409-Q1)

• VIN Range:6 V to 75 V (LM3409HV,LM3409HV-Q1)

• Differential,High-Side Current Sense

• Cycle-by-Cycle Current Limit

• No Control Loop Compen sation Required

• 10,000:1 PWM Dimming Range

• 250:1Analog Dimming Range

• Supports All-Ceramic Output Capacitors and Capacitor-less Outputs

• Low-Power Shut down and Thermal Shut down

• Thermally Enhanced 10-Pin,HVSSOP Package

Applications

• LED Driver

• Constant Current Source

• Auto motive Lighting

• General Illumination

Device Information

PARTNUMBER PACKAGE BODYSIZE(NOM)
LM3409 HVSSOP(10) 3.00mm × 3.00mm
LM3409 PDIP(14) 19.177mm × 6.35mm
LM3409-Q1 HVSSOP(10) 3.00mm × 3.00mm
LM3409HV HVSSOP(10) 3.00mm × 3.00mm
LM3409HV-Q1 HVSSOP(10) 3.00mm × 3.00mm

Pin Configurationand Functions

BOM List Model Matches Server Steps:

(1) Contact customer service and send BOM-(product list).

(2) Query model (BOM report needs to edit the product and quantity queried).

(3) Specific price and product quality instructions for obtaining products .
