LM1117DTX-5.0/NOPB LM1117DTX-ADJ/NOPB LM1117IDTX-3.3NOPB LM1117IDTX-5.0/NOPB LM1117IDTX-ADJ/NOP Audio Power Amplifier IC
LM1117DTX-5.0/NOPB LM1117DTX-ADJ/NOPB LM1117IDTX-3.3NOPB LM1117IDTX-5.0/NOPB LM1117IDTX-ADJ/NOP Audio Power Amplifier IC
Specifications
Brand Name :
Ti
Model Number :
LM1117DTX-5.0/NOPB
MOQ :
Contact us
Price :
Contact us
Payment Terms :
Paypal, Western Union, TT
Supply Ability :
50000 Pieces per Day
Delivery Time :
The goods will be shipped within 3 days once received fund
Packaging Details :
SOP
Output Current :
800 mA
Output Voltage :
5 V
Number of Outputs :
1 Output
Polarity :
Positive
Quiescent Current :
10 mA
Input Voltage MAX :
15 V
Description

LM1117DTX-5.0/NOPB LM1117DTX-ADJ/NOPB LM1117IDTX-3.3NOPB LM1117IDTX-5.0/NOPB LM1117IDTX-ADJ/NOP Audio Power Amplifier IC

1 Features

  • Space-Saving SOT-223 and WSON Packages

  • Current Limiting and Thermal Protection

  • Output Current 800 mA

  • Line Regulation 0.2% (Maximum)

  • Load Regulation 0.4% (Maximum)

  • Temperature Range

    • – LM1117: 0°C to 125°C

    • – LM1117I: −40°C to 125°C

2 Applications

  • Post Regulator for Switching DC–DC Converter

  • High Efficiency Linear Regulators

  • Battery Chargers

  • Portable Instrumentation

  • Active SCSI Termination Regulator

3 Description

The LM1117 is a low dropout voltage regulator with a dropout of 1.2 V at 800 mA of load current.

The LM1117 is available in an adjustable version, which can set the output voltage from 1.25 to 13.8 V with only two external resistors. In addition, it is available in five fixed voltages, 1.8 V, 2.5 V, 3.3 V, and 5 V.

The LM1117 offers current limiting and thermal shutdown. Its circuit includes a Zener trimmed bandgap reference to assure output voltage accuracy to within ±1%.

A minimum of 10-μF tantalum capacitor is required at the output to improve the transient response and stability.

Device Information

PART NUMBER

PACKAGE

BODY SIZE (NOM)

LM1117, LM1117I

SOT-223 (4)

6.50 mm × 3.50 mm

TO-220 (3)

14.986 mm × 10.16 mm

TO-252 (3)

6.58 mm × 6.10 mm

WSON (8)

4.00 mm × 4.00 mm

TO-263 (3)

10.18 mm × 8.41 mm
