6N137-000E 6N137-500E 6N137-560E RF Integrated Circuits High Speed Optocouplers 10 Mb/s 3750Vrms
6N137-000E 6N137-500E 6N137-560E RF Integrated Circuits High Speed Optocouplers 10 Mb/s 3750Vrms
6N137-000E 6N137-500E 6N137-560E RF Integrated Circuits High Speed Optocouplers 10 Mb/s 3750Vrms
6N137-000E 6N137-500E 6N137-560E RF Integrated Circuits High Speed Optocouplers 10 Mb/s 3750Vrms
Specifications
Brand Name :
AVAGO
Model Number :
6N137-000E
MOQ :
Contact us
Price :
Contact us
Payment Terms :
Paypal, Western Union, TT
Supply Ability :
50000 Pieces per Day
Delivery Time :
The goods will be shipped within 3 days once received fund
Packaging Details :
DIP8
Description :
Logic Output Optoisolator 10MBd Open Collector, Schottky Clamped 3750Vrms 1 Channel 1kV/µs CMTI 8-DIP
Height :
4.7 mm
LeCM GROUPh :
9.65 mm
Output Current :
50 mA
Width :
6.35 mm
Fall Time :
10 ns
Operating Supply Voltage :
5 V
Description

6N137-000E 6N137-500E 6N137-560E RF Integrated Circuits High Speed Optocouplers 10 Mb/s 3750Vrms

Description

The Broadcom® 6N137, HCPL-26xx/06xx/4661, HCNW137/26x1 are optically coupled gates that combine a GaAsP light emitting diode and an integrated high gain photo detector. An enable input allows the detector to be strobed. The output of the detector IC is an open collector Schottky-clamped transistor. The internal shield provides a guaranteed common mode transient immunity specification up to 15,000 V/μs at Vcm = 1000V.

This unique design provides maximum AC and DC circuit isolation while achieving TTL compatibility. The optocoupler AC and DC operational parameters are guaranteed from – 40°C to +85°C allowing troublefree system performance.

Features

 15 kV/μs minimum Common Mode Rejection (CMR) at VCM= 1 kV for HCNW2611, HCPL-2611, HCPL-4661, HCPL-0611, HCPL-0661

 High speed: 10 MBd typical
 LSTTL/TTLcompatible
 Low input current capability: 5 mA
 Guaranteed AC and DC performance over temperature: –40°C to +85°C
 Available in 8-Pin DIP, SOIC-8, widebody packages

 Strobable output (single channel products only)
 Safety approval

  •  VIORM = 567 Vpeak for 06xx Option 060
     VIORM = 630 Vpeak for 6N137/26xx Option 060

  •  VIORM =1414 Vpeak for HCNW137/26x1

     MIL-PRF-38534 hermetic version available (HCPL- 56xx/66xx)

Applications

 Isolated line receiver
 Computer-peripheral interfaces
 Microprocessor system interfaces
 DigitalisolationforA/D,D/Aconversion

 Switching power supply
 Instrument input/output isolation
 Ground loop elimination
 Pulse transformer replacement
 Power transistor isolation in motor drives

 Isolation of high speed logic systems

Product tags
