Specifications
Model Number :
MC33179D
Certification :
new & original
Place of Origin :
original factory
MOQ :
10pcs
Price :
Negotiate
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
8600pcs
Delivery Time :
1 day
Packaging Details :
Please contact me for details
Description :
General Purpose Amplifier 4 Circuit 14-SOIC
Supply Voltage (VCC to VEE) :
+36 V
Output Short Circuit Duration :
Indefinite
Maximum Junction Temperature :
+150 °C
Storage Temperature Range :
–60 to +150 °C
Common Mode Rejection (Vin = ±13 V) :
110 dB
Power Supply Rejection :
110 dB
Description

MC33178 MC33179

HIGH OUTPUT CURRENT LOW POWER, LOW NOISE OPERATIONAL AMPLIFIERS

The MC33178/9 series is a family of high quality monolithic amplifiers employing Bipolar technology with innovative high performance concepts for quality audio and data signal processing applications. This device family incorporates the use of high frequency PNP input transistors to produce amplifiers exhibiting low input offset voltage, noise and distortion. In addition, the amplifier provides high output current drive capability while consuming only 420 µA of drain current per amplifier. The NPN output stage used, exhibits no deadband crossover distortion, large output voltage swing, excellent phase and gain margins, low open–loop high frequency output impedance, symmetrical source and sink AC frequency performance.

The MC33178/9 family offers both dual and quad amplifier versions, tested over the vehicular temperature range, and are available in DIP and SOIC packages.

• 600 Ω Output Drive Capability

• Large Output Voltage Swing

• Low Offset Voltage: 0.15 mV (Mean)

• Low T.C. of Input Offset Voltage: 2.0 µV/°C

• Low Total Harmonic Distortion: 0.0024% (@ 1.0 kHz w/600 Ω Load)

• High Gain Bandwidth: 5.0 MHz

• High Slew Rate: 2.0 V/µs

• Dual Supply Operation: ±2.0 V to ±18 V

• ESD Clamps on the Inputs Increase Ruggedness without Affecting Device Performance

MAXIMUM RATINGS

Rating Symbol Value Unit
Supply Voltage (VCC to VEE) VS +36 V
Input Differential Voltage Range VIDR (Note 1) V
Input Voltage Range VIR (Note 1) V
Output Short Circuit Duration (Note 2) tSC Indefinite sec
Maximum Junction Temperature TJ +150 °C
Storage Temperature Range Tstg –60 to +150 °C
Maximum Power Dissipation PD (Note 2) mW

NOTES:

1. Either or both input voltages should not exceed VCC or VEE.

2. Power dissipation must be considered to ensure maximum junction temperature (TJ) is not exceeded. (See power dissipation performance characteristic, Figure 1.)

ORDERING INFORMATION

Op Amp Function Fully Compensated Operating Temperature Range Package
Dual

MC33178D

MC33178P

TA = –40°C to +85°C

SO–8

Plastic DIP

Quad

MC33179D

MC33179P

TA = –40°C to +85°C

SO–14

Plastic DIP
