Specifications
Brand Name :
TI
Model Number :
6N136
Certification :
Original Factory Pack
Place of Origin :
brand new
MOQ :
20pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
5200PCS
Delivery Time :
1 Day
Packaging Details :
please contact me for details
Description :
Optoisolator Transistor with Base Output 5300Vrms 1 Channel 8-DIP
Supply and output voltage range, VCC and VO :
–0.5 V to 15 V
Reverse input voltage :
5 V
Emitter-base reverse voltage :
5 V
Peak input forward current (pulse duration = 1 ms, 50% duty cycle, see Note 1) :
50 mA
Peak transient input forward current (pulse duration 1 µs, 300 Hz) :
1A
Description


6N135, 6N136, HCPL4502 OPTOCOUPLERS/OPTOISOLATORS

► Compatible with TTL Inputs
►High-Speed Switching . . . 1 Mbit/s Typ
►Bandwidth . . . 2 MHz Typ
►High Common-Mode Transient Immunity . . . 1000 V/µs Typ
►High-Voltage Electrical Insulation . . . 3000 Vdc Min
►Open-Collector Output
►UL Recognized... File Number 65085



descriptioN
These high-speed optocouplers are designed for use in analog or digital interface applications that require high-voltage isolation between the input and output. Applications include line receivers that require high common-mode transient immunity, and analog or logic circuits that require input-to-output electrical isolation.

The 6N135, 6N136, and HCPL4502 optocouplers each consists of a light-emitting diode and an integrated photon detector composed of a photodiode and an open-collector output transistor. Separate connections are provided for the photodiode bias and the transistor-collector output. This feature, which reduces the transistor base-to-collector capacitance, results in speeds up to one hundred times that of a conventional phototransistor optocoupler.

The 6N135 is designed for TTL/CMOS, TTL/LSTTL, and wide-band analog applications. The 6N136 and HCPL4502 are designed for high-speed TTL/TTL applications. The HCPL4502 has no base connection.
