5000 Series Marine Aluminum Sheet Corrosion Resistant For Yachts Boats
5000 Series Marine Aluminum Sheet Corrosion Resistant For Yachts Boats
Specifications
Brand Name :
SR or OEM
Model Number :
Al sheet 018
Certification :
SGS, BV
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
5000 tons per month
Delivery Time :
5 - 30 days
Packaging Details :
Ocean Safe Package, Wooden Pallets/ Cases
Item name :
Aluminum alloy marine grade for Marine,Yachts, boats, ships, 5083, 5052, 5086
Temper :
O H T
Length :
2000-12000 or customized
Width :
1200-2600mm or customized
thickness :
3-80mm 0r customized
Material :
Aluminum alloy 5000 series
Description

5000 Series Marine Aluminum Sheet Corrosion Resistant For Yachts Boats

Parameters about marine aluminum sheet (for reference):

1. Temper: O H
2. Length Customized specially
3. Width Customized specially(1200mm-2600mm)
4. Thickness Customized specially(3mm-80mm)
5. Surface treament Mill finish, anodized, textured
6. Material Aluminum alloy 5xxx series

Chemical composition of 5052 / 5083 / 5086 aluminum alloy:

Alloy (%) 5052 5083 5086
Si 0.25 0.40 0.40
Fe 0.40 0.40 0.50
Cu 0.10 0.10 0.10
Mn 0.10 0.40_ 1.0 0.20_ 0.7
Mg 2.2_ 2.8 4.0_ 4.9 3.5_ 4.5
Cr 0.15_ 0.35 0.05_ 0.25 0.05_ 0.25
Ni _ _ _
Zn 0.10 0.25 0.25
Ti _ 0.15 0.15
Each (Others) 0.05 0.05 0.05
Total (Others) 0.15 0.10 0.10
Al Remaining Remaining Remaining

Properties of Marine Grade Aluminum:

Alloy 5083 plate is known for its exceptional strength and performance in extreme environments. 5083 aluminum plate has exceptional thermal conductivity and higher strength than 5052. 5083 aluminum plate is resistant to attack by both sea water and harsh industrial chemical environments. It retains exceptional strength after welding and performs superbly during laser cutting. It has the highest strength of the non-heat treatable alloys.

Application of aluminum alloy on the ship/boat:

Application Alloy Product type
Side of the boat, bottom of the boat 5083,5086,5456,5052 Sheet and aluminum profile
keel 5083 Sheet
Holder 5083 Aluminum profile and sheet
Floor plate 5083,6061 Sheet
Pedestal of engine 5083 Sheet
Deck 5052,5083,5086,5456,5454,7039 Aluminum profile and sheet

Wheelhouse

5083,6N01,5052

Aluminum profile and sheet
Bulwark 5083 Aluminum profile and sheet
Chimney 5083,5052 Sheet
Top and side plate of ship container. 3003,3004,5052 Sheet
Porthle 5052,5083,6063 Aluminum profile and sheet and casting product
Accommodation ladder 5052,5083,6063,6061 Aluminum profile
Mast 5052,5083,6063,6061 Aluminum tube, aluminum bar and profile
The structural material of ship container 6063.6061.7003 Aluminum profile
