O H112 H116 H32 5000 Series Aluminum Sheet With Good Weldability
O H112 H116 H32 5000 Series Aluminum Sheet With Good Weldability
O H112 H116 H32 5000 Series Aluminum Sheet With Good Weldability
O H112 H116 H32 5000 Series Aluminum Sheet With Good Weldability
Specifications
Brand Name :
SR or OEM
Model Number :
5083 aluminum sheet
Certification :
SGS, BV
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
1000 tons per month
Delivery Time :
5 - 30 days
Packaging Details :
Ocean Safe Package, Wooden Pallets/ Cases
Keywords :
5083 aluminum sheet
Temper :
O H112 H116 H32
Application :
Ship, automobile, aircraft welding parts, subway light rail, missile parts, etc
Feature :
corrosion resistance, durable, economic and environmental protection
Alloy :
5083
Item name :
Good Weldability O H112 H116 H32 5083 aluminum sheet
Description

Good Weldability O H112 H116 H32 5083 aluminum sheet

5083 aluminum sheet/ plate is widely used in the high-end field of aluminum processing industry.With the booming development of the domestic rail transit market and the arrival of the global automobile era, there is a huge market prospect.Through alloy composition determination, casting process optimization, homogenization heat treatment and rolling process test, the performance can meet the processing needs of complex parts such as Marine aluminum plate, rail transit, high-end car, and so on, and the application prospect is very broad

Properties Conditions
T (°C) Temper
Density (×1000 kg/m3) 2.66 25
Poisson's Ratio 0.33 25
Elastic Modulus (GPa) 70-80 25
Tensile Strength (Mpa) 305 25 H112
Yield Strength (Mpa) 195
Elongation (%)
Reduction in Area (%)
Shear Strength (MPa) 170 25 O
Fatigue Strength (MPa) 160 25 H321

Performance advantage

1, low density, high strength, Marine aluminum, lightweight automotive aluminum, aerospace aluminum, aluminum tank car special;

2, corrosion resistance, durable, economic and environmental protection;

3. Good arc welding performance and beautiful surface after anodized treatment;

4. No oil spots, waves, scratches, roller marks, neat cutting edges and burrs on the surface of aluminum plate;

Thermal Properties

Properties Conditions
T (°C) Treatment
Thermal Expansion (10-6/ºC) 23.4 20-100
Thermal Conductivity (W/m-K) 120 25 All

Electric Properties

Properties Conditions
T (°C) Treatment
Electric Resistivity (10-9W-m) 60 25 All

Packing

Standard seaworthy export packing,wooden pallets with plastics protection for the aluminum sheet/plate.

15-20 MT can be loaded into 20' container and 40' container.

The other packing can be made base on the customer requirement.

O H112 H116 H32 5000 Series Aluminum Sheet With Good Weldability

Applications:

*LNG ship construction *Pressure vessels *Storage tanks

*Welded structures (high strength) *Armor plate *Drilling rigs

O H112 H116 H32 5000 Series Aluminum Sheet With Good Weldability
