High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086
High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086
High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086
High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086
High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086
High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086
High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086
High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086
High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086
High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086
Specifications
Brand Name :
SR or OEM
Model Number :
5086 Aluminum sheet
Certification :
SGS, BV
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
1000 tons per month
Delivery Time :
5 - 30 days
Packaging Details :
Ocean Safe Package, Wooden Pallets/ Cases
Temper :
H116 H34 H32
Material :
5086 Aluminum
Alloy :
5086
Application :
boat building,Aviation
Keywords :
5086 Aluminum sheet
Item name :
ASTM B209 H116 H34 H32 5086 Aluminum sheet
Width :
200-2600mm
Length :
customized
Thickness :
0.2-600mm
Sample :
Available
Description

ASTM B209 H116 H34 H32 5086 Aluminum sheet


5086 aluminum plate has high strength capacity than 5052 and 5083 aluminum plate, but it is not strengthened by heat treatment, instead becoming stronger due to strain hardening or cold mechanical working of the material.3.0%-4.5% of magnesium is added to 5086 aluminum plate, which enable it to have high strength. Heat treatment does not strongly affect the strength, 5086 aluminum plate can be readily welded and retain most of its mechanical strength.

for boat

Alloy No. Thickness Width Length Temper
(mm) (mm) (mm)
5086 0.2-600 200-2600 customized H116 H34 H32
Packing Export wooden pallets. The bundle wegiht not exceed 2MT. Loading:by 1x20GP
The inner size of container is below:
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM,23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM,27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM,27MTS
Standards ASTM-B209. EN573-1, GB/T3880.1-2006
Quality of material totally free from defects like white rust, oil patches, roll marks, edge damage, camber, dents, holes, break lines, scratches and free from coil set

High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086

Mechanical Properties

Properties Conditions
T (°C) Treatment
Density (×1000 kg/m3) 2.65 25
Poisson's Ratio 0.33 25
Elastic Modulus (GPa) 70-80 25
Tensile Strength (Mpa) 270 25 H112
Yield Strength (Mpa) 130
Elongation (%) 14
Reduction in Area (%)
Shear Strength (MPa) 185 25 H34

Electric Properties

Properties Conditions
T (°C) Treatment
Electric Resistivity (10-9W-m) 56 25 All

Thermal Properties

Properties Conditions
T (°C) Treatment
Thermal Expansion (10-6/ºC) 23.9 20-100
Thermal Conductivity (W/m-K) 127 25 All

High strength 5000 Series Aluminum Sheet ASTM B209 H116 H34 H32 5086
