5086 H32 Marine Grade Aluminum For Shipbuilding / Aluminium Sheet
5086 H32 Marine Grade Aluminum For Shipbuilding / Aluminium Sheet
5086 H32 Marine Grade Aluminum For Shipbuilding / Aluminium Sheet
5086 H32 Marine Grade Aluminum For Shipbuilding / Aluminium Sheet
5086 H32 Marine Grade Aluminum For Shipbuilding / Aluminium Sheet
5086 H32 Marine Grade Aluminum For Shipbuilding / Aluminium Sheet
Specifications
Brand Name :
SR or OEM
Model Number :
Al profile 05
Certification :
SGS, BV
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
1000 tons per month
Delivery Time :
5 - 30 days
Packaging Details :
Ocean Safe Package, Wooden Pallets/ Cases
Temper :
H32
Material :
Aluminum alloy
Alloy :
5086
Application :
marine applications
Keywords :
5086 H32 aluminum sheet
Item name :
5086 H32 marine grade aluminum for shipbuilding / aluminium sheet
Width :
600-2600mm
Length :
customized
Thickness :
0.2-600mm
Packaging :
Standard export packing
Description

5086 H32 marine grade aluminum for shipbuilding / aluminium sheet

Marine aluminum alloy according to the different manufacturing process can be divided into deformation aluminum alloy and casting aluminum alloy, because of the Marine aluminum alloy on the strength, corrosion resistance,weldability has special requirements,aluminum magnesium alloy in the most widely used in ships.The main alloy is 5083.5086.5456

Elements Si Fe Cu Mn Mg Cr Zn Ti Others Al
Content 0.4 0.5 0.1 0.2-0.7 3.5-4.5 0.05-0.25 0.25 0.15 0.15 Remain
Alloy
Temper		 Specified Tensile
strength		 Yield
strength		 Elongation
(mm) (MPa) (MPa) (%)
5086-H32

Thickness 0.2-600

Width 600-2600

Length 500-16000

 324 193 12

Other Marine aluminium alloy

Type Alloy Temper Features Applications

Body

 5052 O,H14,H34 Medium strength, good corrosion resistance and formability, strong fatigue strength Superstructure, auxiliary construction, small boat hull
5083 O,H32 Typical welding aluminium alloys, highest strength in non-heat treated alloys, weldability, corrosion resistance and low temperature type Hull main structure
5086 H32,H34 Same welding and corrosion resistance as 5083, lower strength, improved extrusion performance Hull main structure (thin-walled wide extruded section)
5454 H32,H34 Strength 22% higher than 5052, good corrosion resistance and weldability, general formability Hull construction, pressure vessels, piping, etc
5456 O,H321 Similar to 5083, but slightly higher strength, stress corrosion sensitivity Hull and deck
6061 T4,T6 Heat treatment can strengthen the corrosion resistant alloy, high strength, but low welding joint strength, mainly used for the sea water does not contact the screw joint, riveted structure Superstructure, clapboard structure, frame, etc

Fittingout

1050

1200

 H112,O,H12,H24 Low strength, good machinability, weldability and corrosion resistance, high surface treatment Inter finish

3003

3203

 H112,O,H12 Strength 10% higher than 1100, good formability, weldability and corrosion resistance Inside, roof and side panels of LPG

5086 H32 Marine Grade Aluminum For Shipbuilding / Aluminium Sheet5086 H32 Marine Grade Aluminum For Shipbuilding / Aluminium Sheet
