EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility And Welding
EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility And Welding
EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility And Welding
EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility And Welding
Specifications
Brand Name :
SR OR OEM
Model Number :
1100 Aluminum sheet
Certification :
SGS ROSH REACH
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000 ton per month
Delivery Time :
3-5weeks
Packaging Details :
Ocean Safe Package, Wooden Pallets/ Cases
Model :
1100
Color :
Silver
Temper :
H12 H14 H18
Width :
100mm min
Thickness :
0.1-500mm
Length :
500-16000mm
Description

EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility and Welding

Description

1100 is commercially pure aluminum, the content aluminum is 99.00%, it is the most heavily alloyed of the 1000 series, it can not be strengthed by heat treatment. It has excellent ductility, corrosion resistant, welding, low density and strength, it also has good thermal conductivity and electrical conductivity. Other properties are similar as 1050A.The corrosion resistant can be improved by anodising processing which also make the surface more buautiful.

Composition Specification (%)

Alloy Mn Cu Fe + Si Zn Al Others
Each Total
1100 0.05 0.05 - 0.20 0.95 0.10 99 (min) 0.05 0.15

Welding

1100 Aluminum sheet can be readily welded by all conventional methods. There are many sources of energy in modern welding, such as gas flame, arc, laser, electron beam, friction and ultrasonic wave.

EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility And Welding EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility And Welding

Cold Working

This is an ideal alloy for cold working because of the good ductility in the annealed temper. It can be cold formed by bending, drawing or spinning. Normally, it is under room temperature, we can get sheet and plate with accurate dimension and smooth surface by this processing step.

Annealing

For the annealing, it may be necessary after severe cold working, it is done at 650°F(≈343.3°C) for sufficient time to allow for thorough heating and then air cooled.

Physical Properties

Alloy Density
(Ibs/cubic in.)
(1)		 Melting Range Approximately (°F)
(2)(3)		 Average Coefficient
of Thermal
Expansion
68-212°F		 Thermal
Conductivity
(btu-in/ft2hr °F )		 Electrical Conductivity at 68°F
(Percent of International Annealed Copper Standard)		 Electrical
Resistivity
at 68°F (Ohms-Cir.Mil/Foot)
Equal Volume Equal Mass
1100 0.098 1190-1215 13.1 1520 59 194 18
(1) Coefficient to be multiplied by 10-6. Example 12.2 x 10-6 = 0.0000122.
(2) Melting ranges shown apply to wrought products of 1⁄4 inch thickness or greater.
(3) Based on typical composition of the indicated alloys.

Application

Commonly used in rivets,aluminum-plastic panel, bus door, cooker, curtain wall, heat exchanger, ...,etc..

EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility And Welding EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility And Welding EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility And Welding

EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility And Welding EN AW 1100 Aluminum Sheet H12 H14 H18 Temper Excellent Ductility And Welding

SR_Aluminium_datasheet_1100.pdf
