Manual Lubrication 50kg 750W 240V Single Needle Sewing Machine
Manual Lubrication 50kg 750W 240V Single Needle Sewing Machine
Manual Lubrication 50kg 750W 240V Single Needle Sewing Machine
Manual Lubrication 50kg 750W 240V Single Needle Sewing Machine
Manual Lubrication 50kg 750W 240V Single Needle Sewing Machine
Manual Lubrication 50kg 750W 240V Single Needle Sewing Machine
Manual Lubrication 50kg 750W 240V Single Needle Sewing Machine
Manual Lubrication 50kg 750W 240V Single Needle Sewing Machine
Specifications
Brand Name :
Jianglong
Model Number :
JL-8B
Place of Origin :
Dongguan,China
MOQ :
1 set
Price :
USD 277 - 365 per set
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
100000 Set per month
Delivery Time :
5-8 Work days
Packaging Details :
The inner packaging is a foam box, and the outer packaging is a carton
product name :
Sewing machine for leather
Max. Sewing Speed :
2200(r.p.m)
Max.Stitch Length :
0 - 6.5 mm
Diameter of Cylinder Bed :
65 mm
Needle size :
DP*17 (21#)
Presser foot lift :
14 mm
Lubrication :
Manual lubrication
Condition :
new
Description

High Speed Mattress Sewing Single Needle Compound Feed Industrial Sewing Machine​

Product introduce

This is a manual oil-supply lubricated sewing machine. This machine adopts a sliding rod to take up the thread and a vertical rotary hook to hook the thread to form a double-thread lock stitch. The upper and lower shafts are driven by a synchronous toothed belt. The presser foot, the feed dog, and the needle feed synchronously, and the lever type stitch length adjustment mechanism. The high-pressure foot stroke, the high-pressure foot improves the gap and the large stitch length, with the cylindrical sewing table, suitable for the stitching of school bags, travel backpacks, rucksacks, handbags, etc.

Product advantage

The presser foot, feed dog and needle feed synchronously. The sliding rod is used to take up the thread to form a double-thread lock stitch. The upper and lower shafts are driven by a synchronous toothed belt. Optional clutch motor, electronic energy-saving motor (including fixed needle, adjustable speed).

Parameter of machine

Model JL-8B
Number of Needle Single Needle
Max. Sewing Speed 2200(r.p.m)
Max.Stitch Length 0-6.5mm
Diameter of Cylinder Bed 65mm
Presser foot lift 8 mm (by hand) 14 mm(by knee)
Needle size DP*17 (21#)
Hook Small Vertical Hook
Lubrication Manual Lubrication
Working Space 250×110mm
motor Clutch Electric Motor, Electronic Energy-saving Machine
Mechanical Configuration Cylinder-bed
Feed Mechanism Compound Feed
Dimensions 66.6*26.6*51cm
Color White
N.W 32KG

Product details

1. Reverse stitch handle, the reverse stitch handle is in a static state during sewing operation, and the sewing material will be fed back when the reverse stitch handle is pressed down.

Manual Lubrication 50kg 750W 240V Single Needle Sewing Machine


2. Parallel screws, which can fix the edging cylinder frame.

Manual Lubrication 50kg 750W 240V Single Needle Sewing Machine


3. Thread clamp, adjust the tension of the upper thread.

Manual Lubrication 50kg 750W 240V Single Needle Sewing Machine

FAQ

Q1. Is your company a factory or trading company?

A. We are sewing machine factory, we focus on excellence sewing machine.

Q2. How about your machine quality?
A. I cannot answer to you from our side. But our customer said to us our machine quality is good and use it about two years no change voice. After you use it, you will more understand our quality.

Q3.How about your price?
A.The price depends on model. Our price no expensive, but also no very cheap, in general, quality is better than price.

Q4. Can I buy one or two pieces?
A. Normally, our MOQ is 50 pcs. However, we can send one or two pieces machine to your china agent and exported by yourself.

Q5. How can I get a quotation?

A. First please give us your email address and which machine are your interesting.
