Three Phase Auto Wool Yarn Bobbin Winding Machines
Three Phase Auto Wool Yarn Bobbin Winding Machines
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
GUOSHENG
Model Number :
GS001
Certification :
ISO9001
Supply Ability :
1000 Set/Sets per Month auto bobbin winding machine
Packaging Details :
standard wooden cases auto bobbin winding machine
MOQ :
1 Set/Sets
Power(W) :
1100W motor power of cleaner
Dimension(L*W*H) :
2300*1100*1500mm
Weight :
350kg
Condition :
New
Voltage :
3 phased 400V±10%
Application :
bobbin winding waxing machine
Automatic Grade :
Automatic
Production Capacity :
1000m/min
Memory Capacity :
upon request
Name :
bobbin Woollen Yarn winding waxing machine
Function :
Cone Yarn Bobbin Woollen Yarn Winding Machine
Spindle :
4 spindles hank to cone Woollen Yarn winding machine
Color :
White hank to cone Woollen Yarn winding machine
Style :
Electric Motor hank to cone Woollen Yarn winding machine
Operation Plateform :
one or two sides
auto :
yes
Production Place :
changshu textile machinery
power supply :
220v
Waxing String :
YES
After-sales Service Provided :
Engineers available to service machinery overseas
Warranty :
Permanent warranty
Port :
Shanghai, Ningbo, Shenzhen, Guangzhou
Description
yarn winder machine, changshu textile machinery manufacturer
Product Description

Description:

Durable computer control hard winder used for cone to cone hard package,shuttle loom,warper,hosiery machine.The winding speed is controlled by computer,max:1100m/minute.It has easy adjusting radial anti patterning system.The advanced yarn clearing and tension system with photoelectric yarn detecting can avoid knotting and twisting for yarn.Precise and senstive speed testing system can ensure even winding length(weight).The electric turning waxing machine can ensure the waxing quatity and evenness.It's quite suitable for winding yarn of cotton,flax,silk,chemical fiber.

Parameters:

1. Drive: every spindle per motor

2. Winding speed: Cotton: about 800M/min, Fiber: about 600 M/min (Density: 0.2-0.4g/cm3)

3. Has function of Anti-Hard-Edge and Electronic Anti-Stack.

4. Package Dia≤ 220mm; Take-up length: 152mm;

5. Each spindle with length counter;

6. Advanced control panel;

Technical parameters:

Bobbin type

6"(170mm)

Layout

Double-side or one side, can be 4 spindles

Power Supply

Three phases 380V 50/60HZ

Driving

Every spindle per motor

Power Comsumption

0.09KW/spindle

Take-up package

Tube Bobbin (0°) / Cone 4°20, 5°57, 9°15

Package Diameter

Max.250mm

Yarn tension and waxing device

Every spindle has a yarn tension and waxing device

Auto Stop Device

Each spindle install auto stop device

Traverse Device

Mechanical Traverse suit for soft winding

Cleaner device

Every spindle has a Mechanical Knife yarn cleaner

Electronic Yarn Cleaner

Optional installed

Air Splicer

Optional installed

Blower cleaner

Optional installed

Lighting System

Optional installed

Dimensions

L 13700 x W 1050 x H 1650 mm

Machine Application:

GS008S High Speed Soft winding machine, it's mainly for the Yarn Dyeing preparing using, suit for winding like Fiber yarns, Cotton yarns, FDY, Polyester yarns and etc, and it can take up with Conical Cone or Tube bobbins. It has the feature of High Efficiency and well take-up finished shape, can alleviate the intensity of labour for next processing work.

Equipments:
Inverter(MITSUBISHI Brand), Drum(Superplastic Alloy), Motor(Ningbo), Controller(HangZhou)

About US

Three Phase Auto Wool Yarn Bobbin Winding Machines

Packaging & Shipping

Three Phase Auto Wool Yarn Bobbin Winding Machines

Our Services

Three Phase Auto Wool Yarn Bobbin Winding Machines
