Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage
Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage
Specifications
Brand Name :
GANGJI
Model Number :
GSJX-2-52
Certification :
CE ISO
Place of Origin :
CHINA
MOQ :
1set
Price :
negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram, D/A, D/P
Supply Ability :
50 sets per day
Delivery Time :
10-15 working days
Packaging Details :
plastic package+vacuum package+wooden package+iron frame
Product name :
High Quality Wool Polyester 7G Scarf Knitting Machine Textile
Speed :
Max 1.2m/s
Gauge :
3G 3.5G 5-7G 7G 8G 9G 10G 12G 14G 16G
Voltage :
Single phase 220V
Power :
1.3KW
Computerized :
Yes
Warranty :
One year(not include easily-damaged parts)
After-sales service provided :
Engineers available to service machinery overseas, Online support, Video technical support, Field maintenance and repair service, Field installation
Condition :
New
Description

High Quality Wool Polyester 7G Scarf Knitting Machine Textile

  • Machine parameter

GAUGE 3G,3.5G,3-5-7G,5G,6G,7G,8G,9G,10G,12G,13G,14G,15G,16G
SYSTEM THREE SYSTEM SINGLE CARRIAGE
KNITTING WIDTH 52 INCH
KNITTING SPEED MAX.1.2M/SEC
KNITTING FUNCTION TRANFER,TUCK,MISS,JACQUARD,INTARSIA,HIDE OR APPARENT SHAPING.
STITCH DENSITY STITCH SYSTEM CONTROLLED BY STEPPING MOTOR,32 SECTION STITCH SELECTABLE,ADJUSTABLE SCOPE SUPPORTED BY SUBDIVISION TECHNOLOGY:0-650
RACKING CONTROLLED BY AC SERVO MOTOR,RACKING WITHIN 2 INCHES AND WITH FINE ADJUSTIING FUNCTION.
DRIVE SYSTEM SYNCHRONOUS BELT DRIVE,AC SERVO SYSTEM
NEEDLE SELECTION CONTROLLED BY COMPUTER,ELECTRIC MAGNET NEEDLE CHOOSE SYSTEM WITH HIGH EFFICIENCY.
YARN CARRIER 2x8YARN CARRIERS ON EACH SIDE OF 4 GUIDE RAILS,SHIFTABLE ON ANY NEEDLE POSITION
TAKE DOWN ROLLER PROGRAMMED INSTRUCTION CONTROLLED BY STEPPING MOTOR,32 SECTION LEVELS SELECTION ADJUSTABLE AREA:0-100
SINKER SYSTEM ASSIST KNITTING,HAVE VARIOUS RESULTS OF SHAPING AND STOP.
PROTECTION SYSTEM THE MACHINE WILL AUTOMATICALLY ALARM IF YARN BREAKING,FLOAT YARN,REWIND,END OF KNITTING,FAIL OF RACKING,NEEDLE BREAKAGE AND ERROR PROGRAMMING OCCUR ECT.
CONTROL SYSTEM 1,ADOPT LCD SCREEN,INPUT DEVICE:USB,SYSTEM MEMORY 256MB,A GREAT AMOUNT OF DESIGN FILES CAN BE STORED.2,MONITORING MENU,EACH KIND OF OPERATING PARAMETER,CAN BE SHOWN,AND THEY CAN BE ADJUSTED AT ANY TIME WHEN THE MACHINE IS RUNNING.3,DESIGN SYSTEM IS VISUAL AND EASY TO UNDERSTAND AND UPGRAD.4,MULTI LANGUAGE VERSION,THERE ARE CHINESE,ENGLISH ETC.
POWER 220V ,SINGLE-PHASE,HAVE MEMORIZING FUNCTION AT THE POWER-OFF MOMENT

PRODUCT DETAILS

YARN FEEDER
Yarn feeders can be adjusted according to the knitting width of fabric,also can be adjusted by programmable fine tune according to the carriage’s running speed.

PROBE ALARMING DEVICE
Probe alarming device is a breakthrough as compared with the current monotonous detecting mode where the probes sway from side to side.This device is able to completely,safely and effectively realize the detection and avoid the damaged to the fabrics and other failures.So as to ensure the normalized operation of the machine and increase the working efficiency of knitting process.

YARN TRANSPORTATION DEVICE
The yarn transportation device is installed between the yarn bucket and knitting system,which greatly improves the uneven tension caused by overlong yarn journey,When then yarn is sued up or breakage of yarn takes place due to any reason,the sensor in the yarn transportation device will alarm and the machine stops working.This prevents the broken yarn from entering then knitting area,making the connection of yarn easily and avoiding the damages to the quality of fabrics.

POWER FAILURER PROTECTION
With power failure protection,the machine is able to automatically memorize the data upon power failure the and recover the data when the power is restored,so that the machine can continue the pending work according the programmed patterns,which avoids the waste of yarn ans saves the time,without compromising the quality of the fabrics.

Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage

  • Computerized Flat Knitting Machine Details

Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage

Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage

  • Sound Quality Control System

Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage

Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage

  • We Take Every Product Like A Child

Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage

  • The Auxiliary Of Flat Knitting Machine

Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage

  • Guosheng Knitting Machine Around The World

Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage

  • We Attend The Exhibition Every Year

Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage

  • Welcome To Guosheng Machinery Factory

Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage

  • Contact Us Without Hesitation

Wool Polyester 7g Scarf Knitting Machine Textile 52 Inch Three System Single Carriage
