80 Inch Collar Flat Knitting Machine For Collars And Cuffs
80 Inch Collar Flat Knitting Machine For Collars And Cuffs
Specifications
Brand Name :
YIMA
Model Number :
GSJX-1-80
Certification :
CE ISO
Place of Origin :
CHINA
MOQ :
1set
Price :
negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram, D/A, D/P
Supply Ability :
50 sets per day
Delivery Time :
10-15 working days
Packaging Details :
plastic package+vacuum package+wooden package+iron frame
Product name :
T Shirt Single System Jacquard Plain Collar Knitting Machine
Speed :
Max 1.2m/s
Knitting width :
80inch
Gauge :
12-16G
Voltage :
220V
Warranty :
One year(not include easily-damaged parts)
After-sales service provided :
Engineers available to service machinery overseas, Online support, Video technical support, Field maintenance and repair service, Field installation
Knitting style :
Computerized flat knitting
Description

Collar Machine Flat Knitting Machine For Knitting Collars And Cuffs

Main Technology Parameters:
1) Gauge: 12G, 14G, 16G
2) Knitting Width: 40/48/60/80/100/120Inch
3) Knitting Speed: Controlled by servo motor with 24 section speed optional, max speed 1.2m/s
4) Knitting System: Control Box can be programmed, with 6 patterns saved into memory
5) Yarn carrier: 6 yarn carriers on both sides of 3 guide rails
6) Protection system: The maching will automatically alarm if yarn-breaking, spin, floating yarn, rewind, end of knitting, fail of tracking, needle crash, error programming


PRODUCT FEATURES

ModelGSJX-1-80
Gauge5G,6G,7G,8G,9G,10G,12G,13G,14G,15G
Knitting SystemSingle System Double Carriage
Knitting Width80 Inch
Knitting SpeedMax.1.2m/Sec
Knitting FunctionTranfer,Tuck,Miss,Jacquard,Intarsia,Hide Or Apparent Shaping.
Stitch DensityStitch System Controlled By Stepping Motor,32 Section Stitch Selectable,Adjustable Scope Supported By Subdivision Technology:0-650
RackingControlled By Ac Servo Motor,Racking Within 2 Inches And With Fine Adjustiing Function.
Drive SystemSynchronous Belt Drive,Ac Servo System
Needle SelectionControlled By Computer,Electric Magnet Needle Choose System With High Efficiency.
Scissor And ClampIncluding 2 Scissor And 4 Clamps ,Which Individually Controlled By 6 Motors Separately,Located The Both Of Needle Bed Separately,Further To Increase The Work Efficiency And To Reduce Yarn Consumption.
Yarn Carrier1x6 yarn Carriers On Each Side Of 3 Guide Rails,Shiftable On Any Needle Position
Take Down RollerProgrammed Instruction Controlled By Stepping Motor,32 Section Levels Selection Adjustable Area:0-100
Sinker SystemAssist Knitting,Have Various Results Of Shaping And Stop.
Protection SystemThe Machine Will Automatically Alarm If Yarn Breaking,Float Yarn,Rewind,End Of Knitting,Fail Of Racking,Needle Breakage And Error Programming Occur Ect.
Control System1,Adopt Lcd Screen,Input Device:Usb,System Memory 256mb,A Great Amount Of Design Files Can Be Stored.2,Monitoring Menu,Each Kind Of Operating Parameter,Can Be Shown,And They Can Be Adjusted At Any Time When The Machine Is Running.3,Design System Is Visual And Easy To Understand And Upgrad.4,Multi Language Version,There Are Chinese,English Etc.
Power220v ,Single-Phase,Have Memorizing Function At The Power-Off Moment


80 Inch Collar Flat Knitting Machine For Collars And Cuffs
APPLICATION FIELDS
80 Inch Collar Flat Knitting Machine For Collars And Cuffs
ABOUT US
Guosheng is the professional manufacturer of flat knitting machine since 1992.Until now,it has exported to more than 35 countries.
We pursue quantity and quality,as it’s our responsibility to give you a satisfactory purchasing experience.
Guosheng has a complete inventory system, which can meet the needs of every customer, and sets the delivery period at about 10-15 days.Even if you require customization, our assembly line can effectively improve work efficiency and greatly shorten the delivery time.
80 Inch Collar Flat Knitting Machine For Collars And Cuffs
STRONG AFTER-SALE SERVICE TEAM
You will get free machine operation training & pattern-designing training as soon as you buy our machine.
Mature and attentive service is what Guosheng hold as the principle of service,machine operation training for free and pattern-designing training for free to free customers from all the worries.
80 Inch Collar Flat Knitting Machine For Collars And Cuffs
PACKAGE AND TRANSPORT
To make sure the product you buy is safe during transportation,we use plastic package+wooden package.
In addition,we provide complete packaging methods according to your requirement,and provide convenience for loading,uploading and storage as well as save time for checking and delivery.
80 Inch Collar Flat Knitting Machine For Collars And Cuffs
CERTIFICATIONS
