RGB 3 In1 DC12V 24V Swimming Pool Lights Led Underwater 4 X 2W
RGB 3 In1 DC12V 24V Swimming Pool Lights Led Underwater 4 X 2W
RGB 3 In1 DC12V 24V Swimming Pool Lights Led Underwater 4 X 2W
RGB 3 In1 DC12V 24V Swimming Pool Lights Led Underwater 4 X 2W
RGB 3 In1 DC12V 24V Swimming Pool Lights Led Underwater 4 X 2W
RGB 3 In1 DC12V 24V Swimming Pool Lights Led Underwater 4 X 2W
Specifications
Brand Name :
A.L
Model Number :
AL-B4Y
Certification :
CE,RoHS
Place of Origin :
Guangdong,China
MOQ :
5pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union,Paypal
Supply Ability :
2,00pcs per day
Delivery Time :
Sample and small order 2-4workdays,bulk order 8-12 workdays
Packaging Details :
4pcs/CTN (36x19x24CM),Weight 8Kg
Power :
6 x 2W
Beam Angle :
25°/30°/35°/45°
LED Chip :
Osram High Power LED
Lens :
Asymmetrical and symmetrical
Lamp Size :
D135 x H58MM
Warranty :
2years
Description


4 x 2W High Power RGB 3in1 LED Underwater Light With 316 Stainless Steel DC12V 24V


Description

This is a high quality led underwater light used for pools lighting.
Front cover and lamp body use molding shaped SUS 316 or 304 stainless steel.
Various color optional(Red/Gree/Blue/Yellow/Pink/Warm White/Cool White/RGB/RGB 3in1),meet different
lighting and decoration projects.18x2W high power optional.
Asymmetrical and symmetrical lens optional.250MM diameter,large lighting area.


Parameters

Model No. AL-B4Y
Input Voltage DC12/24V
Power 4 x 2W
Dimension D180mm x H77m
Sleeve Dimension D156mm x H120m
Color R/G/B/Y/RGB/RGB 3in1/Amber/W/CW/WW
Color Temperature 2700K~6500K
LED Chip OSRAM 2W high power LED
LED Qty 6pcs
Beam Angle 25°/30°/35°/45°
Dimmable YES
IP Grade IP68
Certification CE,RoHS
Warranty 2/3years



Material & Manufacturing Technique

​

1. Molding shaped stainless steel sus316# Housing.

2. Molding shaped stainless steel sus316# front cover.
3. EPDM gasket
4. Step tempered galss,T=8mm
5. IP68 PG-11 copper with nickel-coated
6. Excellent heat conductivity aluminum PCB,coefficient of heat conductivity≥2.0w/mk
7. Constant current driver,Single color LED=2-circuit output,RGB 3in1 LED=6-circuit output
8. -20℃-40℃ application environment,less than 1m depth.
9. H07RN-F power cable 2x1.0m² L=3m(for single color),4x1.0m² L=3m(for RGB).
10.PVC sleeve.



Model Number Infos

Model No. Color Beam Angle Lens Voltage Power
AL-B4Y0602 Single 15/30/45/60° Symmetrical Lens 12V/24VDC 6 x 2W
AL-B4Y0605 RGB 3in1 15/30/45/60° Symmetrical Lens 12V/24VDC 6 x 3W
AL-B4Y0605M RGB 3in1 with DMX 15/30/45/60° Symmetrical Lens 12V/24VDC 6 x 3W
AL-B4Y0607 RGBW 4in1 30° Symmetrical Lens 12V/24VDC 6 x 4W
AL-C4Y0602 Single 45|35° Asymmetrical Lens 12V/24VDC 6 x 2W
AL-C4Y0605 RGB 3in1 45|35° Asymmetrical Lens 12V/24VDC 6 x 3W
AL-C4Y0605M RGB 3in1with DMX 45|35° Asymmetrical Lens 12V/24VDC 6 x 3W


Dimension

RGB 3 In1 DC12V 24V Swimming Pool Lights Led Underwater 4 X 2W


Advantage

  • Molding shaped SUS 316 stainless steel as lamp housing and front cover,never rust,even in sea water.itanium plating treatment,surface is smooth and clean,ultra waterproof.
  • EPDM gasket,IP68 waterproof.
  • OSRAM,CREE top quality high LED chip,high bright,long lifetime.
  • Various color optional,red,green,blue,amber,yellow,pink,RGB,RGB 3in1.
  • CE and RoHS,two years warranty.
  • 10 years professional manufacturing and exporting experience.
  • Asymmetrical and symmetrical lens optional,beautiful lighting effect.


Product Photoes

RGB 3 In1 DC12V 24V Swimming Pool Lights Led Underwater 4 X 2W


Asymmetrical And Symmetrical Lens

RGB 3 In1 DC12V 24V Swimming Pool Lights Led Underwater 4 X 2W
Asymmetrical lens: 35°/45° Symmetrical lens: 25°/30°

Warm Tip & Warning

  • The lamp must be installed underwater to prevent the light from the burning up because of over-heating.
  • Pls connect the lamp to 12V or 24V voltage,don't connect



Application

Swimming pool lighting,garden pool lighting,music fountain,ect..

RGB 3 In1 DC12V 24V Swimming Pool Lights Led Underwater 4 X 2W


Payment

  • T/T:HSBC global bank,30%T/T deposit,70% balance settled before shipping.
  • West Union/Paypal:Small order/sample order.
  • L/C:Large qty order.


Delivery

  • Sample order/Small order:3-7 days
  • Big order:15-25days according to your quantity
