Specifications
Brand Name :
A.L
Model Number :
AL-2SD
Certification :
CE,RoHS
Place of Origin :
Guangdong,China
MOQ :
5pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union,Paypal
Supply Ability :
2,000pcs per day
Delivery Time :
Sample and small order 2-4workdays,bulk order 8-12 workdays
Packaging Details :
7pcs/CTN (27x27x29CM),Weight 8Kg
Power :
2W
Input :
24V;120V;240V
Material :
316 Stainless Steel,Die-casting Aluminum
Cable Length :
0.5m or longer
name :
underground garden lights
Warranty :
Two years
Description

High Power P67 LED Underground Light With PC Cover PVC Sleeve

Quick Details

  • Power:2W
  • Voltage:24V,120V,240V
  • Color:R/G/B/Y/RGB 3in1/WW/CW/W
  • Light Size:Φ116mm x H73mm
  • Lens:Symmetrical & Asymmetrical
  • Beam Angle:120°
  • Material:304/316 stainless steel + Die-casting aluminum
  • Warranty:Two years

Description

This is a surface underground lights with SMD LED.We add one white PC cover with the lamp,so the beam angle is 120degree,it's perfect for surface lighting.

Technical Datas

Model No. AL-2SD
Input Voltage 24V,120V,240V
Power 2W
Light Size Φ116mm x H73m
Sleeve Size Φ110mm x H118m
Color R/G/B/Y/RGB 3in1/Amber/W/CW/WW
Color Temperature 2700K~6500K
LED Chip SMD LED
LED Qty 16pcs/6pcs
Beam Angle 120°
Dimmable YES
IP Grade IP67
Weight 1.14Kg
Front Cover 304 / 316 Stainless Steel
Housing Die-casting aluminum
Sleeve PVC
Carton Package Dimension 27 x 27 x 29CM/8pcs
Carton Package Weight 7Kg
Certification CE,RoHS
Warranty 2/3years

Material & Manufacturing Technique

Housing:12# Die-casting grey powder coated aluminum

Front cover:stainless steel sus316#.

Lens:Asymmetrical and symmetrical optical lens,efficiency≥85%

Gasket:Molding shaped silicone seal

Glass:Step tempered galss,T=8mm

Cable gland:IP68 PG-9 copper with nickel-coated.

LED:SMD LED

Loading capacity:Exert force area of Φ10=1330Kgs, Φ30=1840Kgs

Applicaation environment: -20℃-40℃

Power cable:24VDC low voltage:

H05RN-F 2x1.0mm² L=0.5M

Main voltage:

H05RN-F 3x1.0mm² L=0.5M

RGB 24VDC

H05RN-F 4x0.75mm² L=0.5M

Mounting Sleeve:015PVC

Model Information

Model No. Color Cover Shape Power
AL-2SDR0302 W/WW/CW/R/G/B/Y Round 16xSMD
AL-2SDR0305 RGB 3in1 Round 6xSMD
AL-2SDR0305M RGB 3in1 with DMX512 Round 6xSMD
AL-2SDS0302 W/WW/CW/R/G/B/Y Square 16xSMD
AL-2SDS0305 RGB 3in1 Square 6xSMD
AL-2SDS0305M RGB 3in1 with DMX512 Square 6xSMD

Product Advantage

  • RGB 3in1 LED as option,your lighting project is more than that beautiful.
  • Add a PC cover,anti glare lighting effect.
  • Energy-conservation, environment-protection.
  • SUS 316 stainless steel trim:anti corrision and rusty.
  • IP67,apply for outdoor installation.

Dimension

P67 LED Underground Lamp , Underground Landscape Lights With PC Cover PVC Sleeve

Application

Ideal for landscape and facade lighting and any similar applications

P67 LED Underground Lamp , Underground Landscape Lights With PC Cover PVC Sleeve

Tag

LED underground light,LED ingroud light,SMD LED underground light,SMD LED inground light,316 Stainless steel trim LED underground light,Surface LED underground light,LED garden flood light,

Stair LED underground light,Surface Light,Lawn Light.
