Window Protection Fender Welded Wire Mesh Excellent Corrosion Resistance
Window Protection Fender Welded Wire Mesh Excellent Corrosion Resistance
Window Protection Fender Welded Wire Mesh Excellent Corrosion Resistance
Window Protection Fender Welded Wire Mesh Excellent Corrosion Resistance
Window Protection Fender Welded Wire Mesh Excellent Corrosion Resistance
Window Protection Fender Welded Wire Mesh Excellent Corrosion Resistance
Window Protection Fender Welded Wire Mesh Excellent Corrosion Resistance
Window Protection Fender Welded Wire Mesh Excellent Corrosion Resistance
Specifications
Brand Name :
FD
Model Number :
welded wire mesh
Certification :
ISO9001:2008
Place of Origin :
Hebei, China (Mainland)
MOQ :
100 Rolls
Price :
Consultation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2000 Roll/Rolls per Month
Delivery Time :
Shipped in 15 days after payment
Packaging Details :
Moisture-proof paper inside and plastic film coated outside, special requires can be accepted.
Weave Style :
welded
Hole Shape :
Square
Process :
Galvanized after weaving or galvanized before weaving
width :
0.5m to 2.2m
Application :
Construction Wire Mesh
Wire Gauge :
0.20 to 2.5mm
Description

Square Stainless Steel Welded Wire Mesh, BWG4#, Low Carbon Iron

Name: Welded Wire Mesh Mesh:1/4''-6'' Wire dia:0.30-6.50mm Surface:galvanized or PVC coated

Certificate: ISO9001:2008 Welded Wire Mesh Surface: Galvanized and PVC or Stainless Steel

Mesh:1/4''-6" Wire Diameter:0.3-6.5m Width:0.5-1.8m Standard roll length:30m

Storage : Some product available from stock

Specifications

Materials: Galvanized iron wire, stainless steel wire, PVC coated wire

Patterns: Welded before weaving, after weaving, galvanized before weaving and after weaving

Characters: strong welded points and bright luster.The mesh doesnt come loose even if cut in parts or

beingexerted force on parts .Compared with general iron wire ,the products are better in respects of

anti-corrosive and anti-rust .

Usage: They are widely used in industry, agriculture, construction, transport and mining .Such as machine

protection cover, ranch fender, garden fence, window protection fender, passage fender, fowl cage, egg

basket, foodstuffs basket, etc.

Specification list of Welded wire mesh

Opening

Wire diameter(BWG)

In inch

In metric unit(mm)

1/4’’*1/4’’

6.4mm*6.4mm

22,23,24

3/8’’*3/8’’

10.6mm*10.6mm

19,20,21,22

1/2’’*1/2’’

12.7mm*12.7mm

16,17,18,19,20,21,22,23

5/8’’*5/8’’

16mm*16mm

18,19,20,21,

3/4’’*3/4’’

19.1mm*19.1mm

16,17,18,19,20,21

1’’*1/2’’

25.4mm*12.7mm

16,17,18,19,20,21

1-1/2’’*1-1/2’’

38mm*38mm

14,15,16,17,18,19

1’’*2’’

25.4mm*50.8mm

14,15,16

2’’*2’’

50.8mm*50.8mm

12,13,14,15,16

Technical Note:

1.Standard roll length:30m;width:0.5m to 1.8m

2. Special sizes available at request

3. Packing: in waterproof paper in roll.Custom packing available at request.

Galvanized Fencing Mesh

Opening

Wire Diameter<BWG>

In inch

In metric unit(mm)

2’’*3’’

50mm*75mm

2.0mm,2.mm,1.65mm

3’’*3’’

75mm*756mm

2.67mm,2.41mm,2.11mm,1.83mm,1.65mm

2’’*4’’

50mm*100mm

2.11mm,2.5mm

4’’*4’’

100mm*100mm

2.0mm,2.5mm

Window Protection Fender Welded Wire Mesh Excellent Corrosion Resistance

Window Protection Fender Welded Wire Mesh Excellent Corrosion Resistance

Window Protection Fender Welded Wire Mesh Excellent Corrosion Resistance
