Ndt Digital Multi Channel Ultrasonic Flaw Detector 110dB
Ndt Digital Multi Channel Ultrasonic Flaw Detector 110dB
Specifications
Brand Name :
Desisen
Model Number :
HY-350
Certification :
CE,Rosh
Place of Origin :
china
MOQ :
1
Price :
personnally dicuss
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100
Delivery Time :
10-20days
Packaging Details :
260X140X55mm
Duration of work :
Using imported nickel-metal hydride battery, automatic protection charging (18VDC, 220VAC), can work continuously for more than 6 hours.
working mode :
Single probe, twin probe, penetration probe
No need to carry test blocks for on-site inspection :
Custom flaw detection processes can be generated based on actual workpieces such as welds, forgings, castings, pipes, plates, axles, wheels, small pipe diameters, etc
Light weight :
Only 1.6Kg with battery
High automation performance :
Automatic measurement of instrument and probe performance, automatic instrument calibration, can measure thickness and material sound velocity
Description

ultrasonic flaw detectorTen independent inspection channels nickel-metal hydride batteries

Technical indicators:
1, gain range :110dB
2. Bandwidth :0.4~20.0MHz
3, detection range :0~10000.0mm
4, sensitivity margin :>56dB (deep 200mmΦ2 flat bottom hole)
5, resolution :>40dB
6. Dynamic range :>32dB
7. Horizontal linearity :<0.1%
8, vertical linearity :<3%
9, noise level :<10%
10, working mode: single probe, twin probe, penetration probe
11, pulse generator: variable pulse generator
12, damping :50/100/400 euro automatic matching
13, attenuator accuracy: < ±1dB/12dB
14, digital suppression :0 ~ 80%, does not affect linearity and gain
15, gate: incoming wave gate, lost wave gate; Single gate reading, double gate reading
16, alarm: buzzer alarm, LED light alarm
17, ambient temperature :(-10~50)℃
18, relative humidity :(20~95)%RH
