500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field
Specifications
Brand Name :
Leyond-high mast light
Model Number :
LY-ST23500PW
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
1pc
Price :
Negotiation
Payment Terms :
Western Union, T/T，PayPal
Supply Ability :
10,000pcs Per month
Delivery Time :
3-5business days after received the payment
Packaging Details :
Standard export carton 1pcs/carton,WG:21kg, Cartion Size:79×63×20cm
Product name :
Modular Led Light
Power :
500w avaliable
LED chip :
Bridgelux
LED driver :
Meanwell
Luminous efficiency :
150lm/w
PF :
>0.95
CCT :
2700K-5700K
IP Rating :
IP65
Warranty :
5 years
Beam Angle :
24°/36°/60°/90°/160°
Website :
www.leyond.com.cn
Skype :
lysales25
Applications :
Billboard,playground,warehouse,tennis court
Description

500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field

Quick Details:

1. Type: LED Flood Light

2. Power:500w

3. Luminous flux:6000lm

4. Input Voltage:AC100-240V

5. Warranty:5years

6. IP Rating:IP65

7. LED Chip:bridgelux

8. Driver:Meanwell

Description:

Excellent heat sink led module design, easier maintenance, waterproof IP65,Optic PC lens, light transmittance>97%

Features:

1. Modular design,each single module 30-50w,we use 30pcs 1w power leds that encapsulated with Bridgelux chips,which soldered on the Aluminium PCB board,this is for better heat sink.

2. World top Calss MeanWell Driver with 5years warranty at least,high lumens and more stability

3. multi-optional optical lense,multi-optional beam angles: 24°/36°/60°/90°(flood light), 160°(high mast light), 145°x90°(tunnel light), 150°x70° (street light)

4. IP Rating:IP65(waterproof)

5. Lamp Power: 60w/80w/100w/120w/150w/200w/250w/300w/400w/500w

6. Certificate: CE,RoHS,UL, SAA

Model
LY-ST23500PW

Product Name
500w Modular Led light

Modules number
10PC
Power
500w

Input Voltage
AC90~305V 50/60Hz
Input Current
2.32A/220VAC
Chip Brand
Bridgelux
Led Qty
300pcs
Driver Brand
2PCS* Meanwell HLG-240-36A
Warranty
5 Years
Power factor
>0.99/115VAC
>0.98/230VAC
Power efficiency
>90%
Luminous flux
60000lm
Luminous efficiency
120lm/W
CRI
>70
CCT
2700K-6500K
Beam Angle
24° 36° 60° 90°/160°
Carton Size
79×63×20cm
Gross weight
21KG
IP Rating
IP65
Meterial
Aluminum +PC
Certification
CE&ROHS

500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field

500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field

500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field

500 Watt High Power LED Flood Lights 120lm/W Efficiency With 5years Warranty for football field

Operation and Storage Condition:

• Operation Ambient Temperature -30 to +60°C, Relative Humidity 20~90%

• Input Voltage 90-305V AC, 50/60Hz

• Storage Ambient Temperature -40 to +85°C, Relative Humidity 5~95%

• Mounting Height : Suitable for 10-15M height

Quality Warranty:

Quality guarantee is based on storing,installing,operating and maintaining correctly in the normal operation condition.

It is not included in our maintaining range when installing inappropriately,breaking the operating rules,and leading to the products damaging.

Our company will maintain the right to either repair,parts replacing,or products exchange during the quality warranty period.

Why Choose Us:

1.Strong R&D Capability

We keep ourselves updating with the world's latest technology,and cultivate a group of skillful professional engineers,which enable us to make high quality products with the advanced technology.

2.Wide Product Range

We can manufacture outdoor lightings which include LED Flood Light,LED High Bay Light,LED Street Light,LED canopy light and so on.

3.Mature Production Technique

We have advanced full automotive machines for production,we have exclusive formula to solve all the problems which may appears during production.

4.Super OEM/ODM Ability

We can offer OEM/ODM services,we have the ability to customize you products for led chips, led lens,or led lights even others can't do.
