Waterproof IP66 30W SMD Aluminium Solar Street Light All In One

Outdoor Waterproof IP66 30W smd All In one Solar led street garden Post Lights with Motion Sensor

1. The intergration of design ,no cable,the installation is very convenient,easy for us to installation.

2. The Mono-crystalline solar panel,LUXEON 3030 Led Chips. lithium iron phosphate battery,intelligent controller integrated Aluminum Alloy shell,

3. Solar Panel Charges in Sunny daytime, light works at night with the power stored by battery, When People leaves 8-10M away, after set times, the light will dim to set brightness, when people comes 8-10 near, the light will turn on.

4. When the products with optically controlled microwave induction infrared sensor, automatic adjustment of intelligent power on rainy days, extend rainy days.

5. The wireless remote control setting device,adjustable lighting time ,lighting power ,automatic detection of battery voltage,read light power parameters,a human body induction function,as long as people go through when full power lighting,no automatic power down alf, restore energy saving mode.

6. time control + light sensor control+ motion sensor control

7. Motion and light sensor built in:solar street light goes on at dusk at 50% brightness. Can go from 50% power to full brightness when motion is detected. Three Intelligent Modes: Bright / DIM / Recharge.

* Bright: motion activates for lighting when motion is detected for security light and to save battery;

*DIM: 50% lighting for saving power when no motion;

*Off/Recharge: automatically turns off in daylight and goes into recharge mode. (working mode can be adjusted according to client's demands).

8. AC/DC Hybrid system for optional:Features a DC detection function. If DC available, the system will automatically switch to lithium battery supply when the battery voltage rise to the DC switching point; the system will automatically switch to DC power supply when the battery voltage falls to the DC switching point; if DC powers off, the system will shut off output when the battery reaches the over-discharge point after continuous discharging.

	Product Name	30W Solar Led Street Light
	Battery	18650 lithium battery 12V 30Ah
	Beam angle	140°
	Solar panel	30W /18V monocrystalline silicon (Life span of 25 years, 80% efficiency)
	Operating time	>12 hours ,Intelligent mode 3-4 days (Affected by local use environment and sunlight)
	Control Mode	Time control + light sensor control + motion sensor control
	Optional	AC/DC Hybrid System
	IP Rating / IK	IP66 / IK10
	Installation height(m)	3-5m

Intelligent Work Mode :

​

LED Chips

Adopting Luxeon 3030 LED High luminous efficiency, Whole lamp output light efficienty > 145lm/w.8% light efficiency higher than the same type lights in the market.

MPPT Controller

Constant pressure type. Stabilize the output voltage of the storage battery, such as constant 12V or 24V.The voltage is not adjustable, and the current varies according to the load power
