32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting
32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting
32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting
32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting
32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting
32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting
32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting
32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting
Specifications
Brand Name :
Leyond
Model Number :
LY-HB39100XX
Certification :
CE, ROHS, ENEC ,CB
Place of Origin :
China
MOQ :
20 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10000 month
Delivery Time :
5-8day
Packaging Details :
Carton box package
Light source :
Lumileds luxeon3030
Ip rating :
IP 66
Item type :
High Bay Lights
Warranty(year) :
5
Application :
outdoor
Lamp body material :
Aluminum
Working temperature(℃) :
-30 -+ 60
Lamp luminous efficiency(lm/w) :
>130
Color temperature(cct) :
WW :2700K-3000K NW:4000K-4500K CW:5000K-6500K
Description

32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting

led highbay light 100w UFO Warehouse Lighting 32000 Lumens Adjustable Bracket ETL-listed

Ip66 Waterproof CRI 70 LED UFO High Bay Light With 60 90 120 Degree Beam Angle

Technical parameter

Par NO Parameter LY-HB39100WW LY-HB39100NW LY-HB39100PW
Inptut voltage AC100V～240V 50/60HZ
Sysem consumption(W) ≤102 ≤102 ≤102
Light Fixture Luminance(lm) 11200 12000 12500
LED type SMD3030 SMD3030 SMD3030
LED QTY 120 120 120
System Efficiency ＞90% ＞90% ＞90%
Driver MEAN WELL
Beam Angle 120° 120° 120°
CRI ＞80 ＞80 ＞80
Color Temperature(CREE) 2700-3200k 4000-4500k 5000-6500k
Meterial Magnesium Aluminum + PC cover
Lifespan(hrs) ＞50000
IP Rating IP66
Product Size(mm) Φ260X178 Φ260X178 Φ260X178
NET Weight(KG) 2.6 2.6 2.6

Facture

Up to 80% Energy-saving compared to metal halide lamp , mercury-free and 100% recyclable,

energy saving and environmental protection

Isolated internal led driver , easy installation , safety guaranteed

High PF value 0.9 above and THD less 15% for decrease of electricity loss

Assembly and Installation
32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting
32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting
Step1. Ensure all power disconnected and turn off the power switch.
Step2. Knowing the inside diameter of the circular ring,then choose
suitable hook for the lamp.
Step3.Fix the hook before installation and enable it to support over 3
times weight of the lamp. Connect the lamp with hook and make
it safe.
Step4. Connect the input cables of lamp to power supply mains and wrap
up the cables with insulated sleeve.
Step5. Switch on the power, the lamp will light on. Refer to the left
figure.
In case of any abnormal phenomenon or problem, please switch off the
power supply then contact with Genice customer service center.

Application

There is widely used in Warehouse , Industrial workshops, Logistics centers, Exhibition halls, Stadiums, Docks, Golf courses, Airport, Highway toll stations, supermarkets Light engineering.

32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting

structure

32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting


  • Distribution Curve​

32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting

package

Carton Size: 360mm×360mm×200mm
Net weight:2.6KG Gross weight:3.7KG
32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting

production

32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting

32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting32000 Lumens ETL Listed LED High Bay Light 100w Warehouse Lighting
