250C 14 AWG Stranded Wire , Nickel Plated Copper Wire UL10486
250C 14 AWG Stranded Wire , Nickel Plated Copper Wire UL10486
250C 14 AWG Stranded Wire , Nickel Plated Copper Wire UL10486
250C 14 AWG Stranded Wire , Nickel Plated Copper Wire UL10486
250C 14 AWG Stranded Wire , Nickel Plated Copper Wire UL10486
250C 14 AWG Stranded Wire , Nickel Plated Copper Wire UL10486
Specifications
Brand Name :
MYSUN
Model Number :
UL10486
Certification :
ROHS/UL/CCC/VDE/CCC/SGS/ISO9001:2008
Place of Origin :
China
MOQ :
5000 pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
50,000m/day
Packaging Details :
305m/roll
rated voltage :
300V
rated temperature :
250℃
insulation :
PFA
conductor :
Nickel-plated copper wire
standard :
UL758
color :
all colors are available
appliance :
home appliance, headlamp, industrial machine, electro thermal products.
Packing :
reel
Name :
multicore cable
size :
4/0-32AWG
name :
high temperature cable
Description

250C 14AWG UL10486 Insulated Wire Nickel-plated copper wire

Specifications:

Nominal voltage:300V

Temperature range:200C

Standard: UL 758

Insulation: PFA

Conductor: Nickel-plated copper wire

appliance:home appliance, headlamp, industrial machine, electro thermal products.

color:all colors are available

Product dimensions:

CONDUCTOR INSULATION MAX.COND RESISTANCE (Ω/KM) UNIT LENGTH (M)(FT)
SIZE (AWG) CONSTRUCTION (NO./mm) DIAMETER (mm) NOMINAL THICKNESS(mm) DIAMETER (mm)
32 7/0.08 0.24 0.25 0.74 589 610(2000)
30 7/0.10 0.30 0.25 0.80 236 610(2000)
28 7/0.12 0.36 0.25 0.86 237 610(2000)
26 7/0.16 0.48 0.25 0.98 152 610(2000)
24 7/0.20 0.60 0.25 1.10 95.30 610(2000)
22 19/0.15 0.75 0.25 1.25 56.10 305(1000)
20 19/0.185 0.93 0.25 1.43 34.60 305(1000)
18 19/0.235 1.17 0.30 1.77 22.20 305(1000)
16 19/0.30 1.50 0.30 2.10 16.60 305(1000)
14 19/0.37 1.85 0.30 2.45 8.78 305(1000)
12 19/0.47 2.35 0.35 3.05 5.70 305(1000)
10 37/0.43 3.00 0.35 3.70 3.95 305(1000)
8 37/0.54 3.78 0.51 4.80 2.62 AS CUSTOMER'S REQUEST
7 37/0.60 4.20 0.51 5.22 1.93
6 37/0.68 4.76 0.51 5.78 1.58
5 37/0.76 5.32 0.51 6.34 1.23
4 37/0.86 6.02 0.80 7.62 1.03
3 7/2.21 6.63 0.80 8.23 0.78
2 7/2.48 7.44 0.80 9.04 0.55
1 7/2.78 8.34 1.20 10.74 0.48
0 7/3.20 9.60 1.20 12.00 0.39
2/0 7/3.57 10.71 1.20 13.11 0.31
3/0 7/3.94 11.82 1.20 14.22 0.24
4/0 7/4.42 13.26 1.20 15.66 0.19

Features and Benefits of PFA

When compared to rubber insulation, PFA is a more suitable alternative, as they are smaller in terms of diameter,

and are lighter in terms of weight. Both these attributes support easy wire installation.

They are particularly useful for applications, which comprise fluctuating voltages and temperatures.

The features of PFA insulated wire include:

  • Chemical resistance
  • Good electrical stability
  • High mechanical strength
  • Low outgassing properties
  • Protects wires during harsh weather conditions
  • Conductor Material: Tinned Copper
  • AWG Rating Range: From 10 to 30 AWG
  • Operating Temperature Range:
  • Static: From -75° C to +200° C
  • Flex: Between -50 °C and 190 °C

These various features and benefits make them the perfect insulation for wires used in gas igniters, scientific instruments,

automotive sensors, and aircraft and marine systems.

Service:

Shipment:

1. by express

2. by sea

Payment terms:

LC, TT, Western Union, Money Gram and PayPal

Delivery:

Sample order: 1-3 working days

Big order: 5-10 working days

Customized order: 10-15 working days
