Fiberglass Insulated Stranded Tinned Copper Wire 1.68-2.66mm Diameter AWM3122
Fiberglass Insulated Stranded Tinned Copper Wire 1.68-2.66mm Diameter AWM3122
Fiberglass Insulated Stranded Tinned Copper Wire 1.68-2.66mm Diameter AWM3122
Fiberglass Insulated Stranded Tinned Copper Wire 1.68-2.66mm Diameter AWM3122
Fiberglass Insulated Stranded Tinned Copper Wire 1.68-2.66mm Diameter AWM3122
Fiberglass Insulated Stranded Tinned Copper Wire 1.68-2.66mm Diameter AWM3122
Fiberglass Insulated Stranded Tinned Copper Wire 1.68-2.66mm Diameter AWM3122
Fiberglass Insulated Stranded Tinned Copper Wire 1.68-2.66mm Diameter AWM3122
Specifications
Brand Name :
Msyun
Model Number :
AWM3122
Certification :
UL/cUL
Place of Origin :
Guangdong
MOQ :
5000 pcs
Price :
Negotiable
Payment Terms :
L/C, D/A, T/T, Western Union,Paypal,HSBC
Supply Ability :
800000 Meters per Day
Delivery Time :
7-10 Working Days
Packaging Details :
305 Meters per Roll and 7 Rolls per Carton
Insulation :
Fiber Glass and Silcicone Rubber
Conductor :
Tinned Copper
Conductor Type :
Stranded
Conductor Construction :
7/0.16 1/0.81 11/0.16 17/0.16 26/0.16 41/0.16 20/0.18 40/0.18
Diameter :
1.68-2.66mm
Max.Cond Resistance :
143-14 Ω/KM
Rated Voltage :
300V
Rated Termperature :
200℃
Standard :
UL758
Application :
Home appliance,headlamp and industrical machines
Color :
8 colors
Flammability rating :
FT-2
Package :
305Meters per Roll
Description

The fiberglass insulated silicone electrical wire tinned copper inside AWM3122

Specifications:

Nominal voltage: 300V

Temperature range: 200C

Standard: UL 758

Conductor: Tinned copper wire

Insulation: Silicone Rubber

Insulation: Fiber Glass

Application : electro thermal products

Product dimensions:

Conductor Insulation Max.cond
resistance
(Ω/km)		 Unit Length
(m) (Ft)
Size
(AWG)		 Construction
(No./mm)		 Diameter
(mm)		 Nominal Thickness
(mm)		 Diameter
(mm)
26 7/0.16 0.48 0.60 1.68 143 305/1000
24 7/0.20 0.61 1.81 89.3
22 7/0.254 0.77 1.97 56.4
20 7/0.31 0.94 2.14 35.2
18 7/0.39 1.19 2.39 22.2
16 7/0.49 1.49 2.69 14
24 1/0.50 0.50 0.65 1.80 89.3 305/1000
22 1/0.65 0.65 1.95 56.4
20 1/0.81 0.81 2.11 35.2
18 1/1.02 1.02 2.32 22.2
16 1/1.20 1.20 2.50 14
24 11/0.16 0.61 0.60 1.81 89.3 305/1000
22 17/0.16 0.76 1.96 56.4
20 26/0.16 0.94 2.14 35.2
18 41/0.16 1.18 2.38 22.2
16 26/0.254 1.49 2.69 14
0.30mm² 12/0.18 0.71 0.60 1.91 59.78 305/1000
0.50mm² 20/0.18 0.92 2.12 40.1
0.75mm² 30/0.18 1.13 2.33 26.7
1.00mm² 40/0.18 1.31 2.51 20
1.25mm² 50/0.18 1.46 2.66 14.35

Fiberglass Insulated Stranded Tinned Copper Wire 1.68-2.66mm Diameter AWM3122

Fiberglass Insulated Stranded Tinned Copper Wire 1.68-2.66mm Diameter AWM3122

FAQ:

1, What’s the MOQ?

One roll. 100M/200M/300M/305M/500M/Roll.

2, How to get the samples?

We have most of the commonly used samples in Stock.

We can offer the free samples immediately.

3, What’s the payment terms?

LC, TT, Western Union, Money Gram and PayPal

4, What’s the delivery date?

Most of the commonly used products are in Stock. We can arrange it within one day.

We will arrange the delivery date as your requirement while the Bulk Production.

5, How to visit your factory/company?

We are located in Shenzhen City, Guangdong Province, closed to Guangzhou, Dongguan and Hong Kong. Only one and a half hours drive away. Convenient for visit.

Service

Shipment:
1. by express
2. by sea

3. by air plane

If you have your own shipper,you can tell me in advance.

My targert is to give my best serivce for you and hope we can have a good cooperation!

Packaging : Hard cardboard carton ( Customizable)


Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days
