UL758 300V 3.70mm PTFE Insulated Copper Wire High Temperature
UL758 300V 3.70mm PTFE Insulated Copper Wire High Temperature
UL758 300V 3.70mm PTFE Insulated Copper Wire High Temperature
UL758 300V 3.70mm PTFE Insulated Copper Wire High Temperature
UL758 300V 3.70mm PTFE Insulated Copper Wire High Temperature
UL758 300V 3.70mm PTFE Insulated Copper Wire High Temperature
UL758 300V 3.70mm PTFE Insulated Copper Wire High Temperature
UL758 300V 3.70mm PTFE Insulated Copper Wire High Temperature
Specifications
Brand Name :
Mysun
Model Number :
UL1180
Certification :
UL/cUL/CCC/CE/RoHS/SGS
Place of Origin :
Guangdong
MOQ :
3050/6100 meters
Price :
Negotiable
Payment Terms :
L/C, D/A, T/T, Western Union,Paypal,HSBC
Supply Ability :
500000 Meters per Day
Delivery Time :
7-10 Working Days
Packaging Details :
305/610 Meters per Roll / 7 Rolls per Carton or can be customized
Item :
PTFE insulated wire
Conductor :
Nickel-plated/silver-plated copper wire
OD :
0.90-3.70mm
Max.Cond Resistance :
3.55-563 Ω/KM
Rated Voltage :
300V
Rated Temperature :
200℃
Standard :
UL758
Color :
8 colors / can be customized
Application :
Home appliance,industrial machines and others
Package :
305/610 Meters per Roll
Insulation :
PTFE
Description

PTFE insulated copper wire high temperature for industrial application

Specifications:

Nominal voltage:300V

Temperature range: 200℃

Standard: UL758

Insulation: PTFE

Conductor: Nickel copper wire

Product dimensions:

Conductor Insulation Max.cond
resistance
(Ω/km)		 Unit Length
(m)(Ft)
Section (AWG) Construction
(No./mm)		 Diameter
(mm)		 Inside thickness(mm) Diameter
(mm)

32

 7/0.08 0.24 0.33 0.90 563 610/2000
30 7/0.10 0.30 0.33 0.96 381 610/2000
28 7/0.12 0.36 0.33 1.02 239 610/2000
26 7/0.16 0.48 0.33 1.14 150 610/2000
24 7/0.20 0.60 0.33 1.23 94.2 610/2000
22 19/0.15 0.75 0.33 1.41 59.4 305/1000
20 19/0.19 0.93 0.33 1.59 36.7 305/1000
18 19/0.235 1.17 0.35 1.87 23.2 305/1000
16 19/0.30 1.50 0.35 2.20 14.6 305/1000
14 19/0.37 1.85 0.35 2.55 8.96 305/1000
12 19/0.47 2.35 0.35 3.05 5.64 305/1000
10 37/0.43 3.00 0.35 3.70 3.55 305/1000

Applications:

* Widely used in lighting, household appliances, , lamps.
* electric appliances, instrumentation, motor wiring and electronics.


Product shoot:

UL758 300V 3.70mm PTFE Insulated Copper Wire High TemperatureUL758 300V 3.70mm PTFE Insulated Copper Wire High Temperature

UL758 300V 3.70mm PTFE Insulated Copper Wire High Temperature


Shipment:
1. by express
2. by sea

If you have your own shipper,you can tell me in advance.

My targert is to give my best serivce for you and hope we can have a good cooperation!


Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days

FAQ:

1. What's the lead time for mess goods?

Lead time will be around 7-15 working days for per order.

2.How can I get the sample?

We will advise the specifications and send data sheet for confirmation. Then sample will be arranged immediately if there is stock available.

3.Whats the sample charge?

Sample will be free if there is stock available and shipping cost will be on buyer's account.

4.Can color be customized?

We have 8 normal colors, white, black,red,brown,yellow,blue,green,yellow/green,transparent. Other colors can be customized.

5.How to make the payment?

T/T, paypal,western union, L/C and so on.
