AN4 / AN 6 Braided Rubber Fuel Hose for Automotive , Stainless Steel Outer
AN4 / AN 6 Braided Rubber Fuel Hose for Automotive , Stainless Steel Outer
AN4 / AN 6 Braided Rubber Fuel Hose for Automotive , Stainless Steel Outer
AN4 / AN 6 Braided Rubber Fuel Hose for Automotive , Stainless Steel Outer
AN4 / AN 6 Braided Rubber Fuel Hose for Automotive , Stainless Steel Outer
AN4 / AN 6 Braided Rubber Fuel Hose for Automotive , Stainless Steel Outer
AN4 / AN 6 Braided Rubber Fuel Hose for Automotive , Stainless Steel Outer
AN4 / AN 6 Braided Rubber Fuel Hose for Automotive , Stainless Steel Outer
Specifications
Brand Name :
PASSION
Model Number :
AN4/AN6/AN8/AN12
Certification :
CE / ISO 9001:2008
Place of Origin :
CHINA
MOQ :
5000m
Price :
USD; 0.5USD/M-0.99USD/M;
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300000M/MONTH
Delivery Time :
Within 30days for 20' container
Packaging Details :
Well packed by good quality braided strap.
Tube :
Fuel / Gasoline Resistant NBR Material
Reinforcement :
High Strength Braided Polyester Thread
Outer Cover :
304 Braided Stainless Steel
W.P. :
20BAR / 300PSI
B.P. :
60BAR/900PSI
Application :
Mainly used for conveying of Gasoline in Automotive Area
Temperature :
-40℃ - +150℃, customized according to application.
Standard length :
50m, 100m.
Steel Material :
304 Stainless Steel
Accessories :
Such as JIC Fittings and other Hose Connectors
Lead Time :
30 days for Full 20' container
Price Term :
EXW or FOB or CIF or DDP
Description

AN4 / AN 6 Braided Rubber Fuel Hose for Automotive , Stainless Steel Outer

Structure: Tube: Pure rubber tube. It can be designed as to be Oil / Fuel / Gasoline resistant hoses according to the requirements of application.

Reinforcement: High tensile polyester fiber braided.

Outer cover: Stainless steel wire, or Aluminium wire, or cotton threads, or polyester fiber lines, which is used for strengthening pressure or protection.

Temperature: -40℃ - +150℃, customized according to application.

Application: Mainly used for conveying of Gasoline / Fuel in Automotive Industry.

Standard length: 50m, 100m.

Specification of the inner hose:

Item code Inner Diameter Outer Diameter Working Pressure Burst Pressure Length Measurement Weight
inch mm mm bar psi bar psi m cbm/roll kg/m
PRA-06　 1/4" 6 13 20 300 60 900 100 0.0256 0.17
PRA-08　 5/16" 8 15 20 300 60 900 100 0.0271 0.22
PRA-10　 3/8" 10 17 20 60 60 900 100 0.036 0.26
PRA-13　 1/2" 13 22 20 300 60 900 100 0.0634 0.4
PRA-16　 5/8" 16 25 20 300 60 900 50 0.1095 0.45
PRA-19 3/4" 19 29 20 300 60 900 50 0.146 0.7
PRA-25　 1" 25 36 20 300 60 900 50 0.171 0.85

AN4 / AN 6 Braided Rubber Fuel Hose for Automotive , Stainless Steel Outer

AN4 / AN 6 Braided Rubber Fuel Hose for Automotive , Stainless Steel Outer

Note: The inner hose can also be Pure rubber tube without fiber braided reinforcement.

If the specifications you need are not in the list, please offer your specification parameters or operating requirements. We’ll check and customize.

Main Market: North America
