Specifications
Brand Name :
PASSION
Model Number :
Flange 87691
Certification :
ISO 9001-2008, CE
Place of Origin :
Zhejiang China
MOQ :
500pcs
Price :
Negotiated
Payment Terms :
T/T, L/C, Western Union, Paypal, MoneyGram
Supply Ability :
60,000 pcs per month
Delivery Time :
Within 20 to 30 days after we receive advance payment
Packaging Details :
Packed in cartons and wooden cases
Part Number :
87691
Size of Hose :
3/16” to 2”
Appearance :
Galvanized zinc
Color :
Silver and Golden
Material :
Carbon Steel 45#
Standard :
Eaton
Technic :
Forge
Machine :
CNC
Description

87691 SAE Hydraulic Hose Fittings FLANGE 6000PSI Flange For Oilfield , Mine Industriy

Descrioption:

It is hydraulic hose fitting 90 degree SAE Flange 87691.

Applications:

Hydraulic Hose Fitting is widely used in the hydraulic and fluid conveying system of machinery,

oilfield, mine, building, transportation and other industries.

Specifications:

90 DEGREE SAE FLANGE 6000PSI ISO 12151-3-SAE J516

87691 SAE Hydraulic Hose Fittings FLANGE 6000PSI Flange For Oilfield , Mine Industriy ( 87691 )

Part No. FLANG SIZE Hose Bore Dimensions
DN DASH A C D H L
87691-08-08 1/2" 12 08 41 31.7 24 48 7.75
87691-12-10 3/4" 16 10 56 41.3 32 56.5 8.76
87691-12-12 3/4" 20 12 65.5 41.3 32 66 8.76
89691-16-12 1" 20 12 65.5 47.6 38 69 9.53
87691-16-16 1" 25 16 76.7 47.6 38 74.5 9.53
87691-16-20 1" 32 20 91.5 47.6 38 85.5 9.53
87691-20-16 1.1/4" 25 16 76.7 54 44 78.5 10.29
87691-20-20 1.1/4" 32 20 91.5 54 44 89.5 10.29
87691-24-20 1.1/2" 32 20 91.5 63.5 51 94.5 12.57
87691-24-24 1.1/2" 40 24 109.4 63.5 51 108 12.57
87691-32-24 2" 40 24 109.4 79.4 67 116 12.57
87691-32-32 2" 50 32 131.8 79.4 67 136.3 12.57

Note: 1 for use with braided hoses, textile hoses and thermoplastic hoses, if use with spiral hoses, hose fitting series number is 87692-**-**.

It is hydraulic hose fittings SAE Flange in silver color.

87691 SAE Hydraulic Hose Fittings FLANGE 6000PSI Flange For Oilfield , Mine Industriy ( 87691 )

87691 SAE Hydraulic Hose Fittings FLANGE 6000PSI Flange For Oilfield , Mine Industriy ( 87691 )

87691 SAE Hydraulic Hose Fittings FLANGE 6000PSI Flange For Oilfield , Mine Industriy ( 87691 )
