Flame Resistant Red / Green 1 / 4 Inch Grade R Twin Hose For Gas Welding
Flame Resistant Red / Green 1 / 4 Inch Grade R Twin Hose For Gas Welding
Flame Resistant Red / Green 1 / 4 Inch Grade R Twin Hose For Gas Welding
Flame Resistant Red / Green 1 / 4 Inch Grade R Twin Hose For Gas Welding
Flame Resistant Red / Green 1 / 4 Inch Grade R Twin Hose For Gas Welding
Flame Resistant Red / Green 1 / 4 Inch Grade R Twin Hose For Gas Welding
Specifications
Brand Name :
PASSION
Model Number :
ID 1/4”
Certification :
ISO 9001-2008, CE
Place of Origin :
Zhejiang China
MOQ :
2,000 m
Price :
Negotiated
Payment Terms :
T/T, LC, Paypal, MoneyGram or Western Union
Supply Ability :
300,000 m per month
Delivery Time :
20 days after received the advance payment
Packaging Details :
Wrapped by transparent OPP film, pallet, color packing can be customized
Material :
SBR & EPDM
Inside Diameter :
6.3 mm+/-0.3
Outside Diameter :
13.2mm+/-0.4
Max. Working Pressure :
300psi (20bar)
Min. Burst Pressure :
900psi (60bar)
Standard Length :
100m roll
Color :
Red & Green
Temperature Range :
-25°C to 80°C
Standard :
EN 559 / ISO 3821
Property :
Good Adhesiveness
Packing :
Wrapped by OPP film, customized packing is available
Main market :
Middle East, America
Reinforcement Layer :
High tensile polyester fiber braided
Description

Flame Resistant Red / Green 1 / 4 Inch Grade R Twin Hose For Gas Welding

Specifications:

Item code

Inner Diameter

Outer Diameter

Working Pressure

Burst Pressure

Length

Measurement

Weight

inch

mm

mm

bar

psi

bar

psi

m

cbm/roll

kg/m

HPR1

3/16"&3/16"

4.8

11.5

20

300

60

900

100

0.04

0.28　

HPR2　

1/4"&1/4"

6.4

13

20

300

60

900

100

0.06

0.34

HPR3　

5/16"&5/16"

7.9

15

20

300

60

900

100

0.07

0.42

HPR4　

3/8"&3/8"

9.5

17

20

300

60

900

100

0.08

0.52

Description:

1, Construction: Tube: SBR + EPDM Synthetic Rubber

Reinforcement: High tensile polyester fiber braided.

Cover: SBR Synthetic Rubber

2, Appearance: Smooth finish

Green or blue outer layer of oxygen rubber hose

Red outer layer of fuel gas hose, e.g. acetylene

3, Applicable temperature: -25°C to +70°C

4, Bend radius: 10 times of proper diameter dimension

5, Package: Common packed by OPP transparent film.

The pallet and woven bag packing are available, the color sticker can be offered, but shall be charged additionally.

6, Trademark: PASSION, OEM is available

7, Property: Anti-ozone aging, Heat-proof aging, Corrosion resistance and excellent flexibility.

8, Certificates: CE, SGS

9, Main market: Middle East, Europe and America

Applications:

This type of rubber hose is applied to gas welding, cutting and attachment procedures e.g. braze welding, medaling and heating and gas cutting of pressure control devices.

Competitive Advantage:

Hangzhou Paishun Rubber And Plastic Co., Ltd, a leading rubber hose manufacturer in the east of China. 8 years manufacturing experience, 50 sets of braiders and 3 production lines.

Free sample can be offered, we can customize as your request.

Cooperative Brand:

WELDMAN, Max Weld, Goldenflex, SAEFLEX. REDI-WELD

Company Slogan:

PASSION FOR HOSE! PASSION FOR YOU!
