Specifications
Brand Name :
BEST
Model Number :
LC-RY5320
Certification :
CE
Place of Origin :
wenzhou
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5 sets/40 days
Delivery Time :
40days
Packaging Details :
Fumigated wooden box
Printing speed :
100m/min
Printing colors :
5 colors
Printing width :
320mm
Name :
Four Color Low Price Adhesive Lable Printing Machine From Ruian Factroy 6 sets UV drying system
color :
customized
voltage :
380
Description

Allfine Group-20 years experience Solution
1:Label production line- flexo print machine,die cutting machine,slitting machine,inspection and rewinding machine
2:Flexible package line-water bottle label PVC,heat transfer Pet, Opp, Pe etc rotogravure printer, dry laminator, PP PE film blowing machine,bag making machine
3:Decal paper,wine and smoking package-Silk screen press machinery, wicket dryer, uv dryer
4:Paper cup production line- flexo printer. die cutting machine, paper cup making machine

1: Save material 2: Improve efficiency 3:Professional tranning 4: Factory built

Partner Manager-Jack Huang
Allfine Group

Four Color Low Price Adhesive Lable Printing Machine From Ruian Factroy 6 sets UV drying system

flexo printing production line.pdf

Performance and characteristics:
1.The main motor adopts imported frequency conversion stepless speed regulation. Discharge and receiving are controlled by magnetic powder brake and clutch (or optional Japanese MITSUBISHI antomatic tension controller.)

2.The feeding device is controlled by the automatic deviation correcting sensor.

3.The ceramic anilox roller, has the characteristics of long service life, wear resistance, corrosion resistance. To reduce the frequency of replacing the roller, improve the printing efficiency favoourable.

4.The printing units are equipped with a group of infrared drying device.

5.Each printing unit infrared drying device interchangeable UV drying device.

6.The rooling device adopted clipping device with air expansion core shaft.

7.The printing unit adopts 360 degree circumferential plate adjustment. Each printing unit can independently gear or release, so that other units continue printing.

8.The roll feeding, printing, polishing, auto infrared drying. Laminating and rewinding a continuity.

9.The product has a wide range of printing, humor and no pollution. The characteristics and the economic benefit is high, fast printing speed etc. is the printing machine paper, cardboard, high-grade self-adhesive trademark ideal for the printing plant.

10.When the roller automatic parking detachment, and low speed rotation, to prevent dry ink.

Technical data:

Model 320 420 520
Max Printing speed 100m/min 100m/min 100m/min
Printing color 1-12colours 1-12colours 1-12colours
Max. width of paper 350mm 450mm 550mm
Max .printing width 320mm 420mm 520mm
Max. unwinding diameter 650mm 650mm 650mm
Max. rewinding diameter 650mm 650mm 650mm
Printing length 175-381mm 175-381mm 175-381mm
Precision of chromatography ±0.1mm ±0.1mm ±0.1mm
Dimensions 2m*1.0m*2.2m 2m*1.1m*2.2m 2m*1.2m*2.2m
Machine weight About 2600kg About 2800kg About 3000kg

Four Color Low Price Adhesive Lable Printing Machine From Ruian Factroy 6 sets UV drying systemFour Color Low Price Adhesive Lable Printing Machine From Ruian Factroy 6 sets UV drying system

HD video link about LC 420 Flexo Label Printing Machine printing paper cups with In mold die cut station and UV dryers
https://youtu.be/SG_vbjCp8L0

video link: label flexo printing machine 5 colors, dual banks ovens
https://www.youtube.com/watch?v=Z9Mxd9PtAec


video link: LC adhesive label flexo printing machine 320mm 5color
https://www.youtube.com/watch?v=s3fnEjgIoPU


5colors 320mm width flexo printing machine for silver subunit paper
https://youtu.be/LM21RhG9s7c

MACHINE NAME: RY SERIES AUTOMATIC UV LABEL FLEXO PRINTING MACHINE
NEW TYPE: one machine finish printing,die cutting,sliting in one process
Remark:The machine also can be equipped with UV,just inform us how many UV you want.Also you can let us your requirement on the machine,we will quote you on your demands.

Sticker Label Production Line:

1. Sticker Label Flexo printing machine
2. Label Die cutting machine to be sheet or to be roll Flat bed
3. Rotary Label Die Cutting Machine
4. Label roll to roll slitting and rewinding machine
5. Label Slitting and rewinding machine with die cut function
6. Label Inspection Machine
5. Flexo Plate Making Machine For Printing Machine
6. Flexo Cylinder Plate Mounter Machine
7. Anilox Roller Ultrasonic Cleaning Machine
10. Label adhesive Coating Machine
11. IML Label Die Cutting Machine
12. unit type Label Printing Machine
