Specifications
Brand Name :
FENGMING
Model Number :
FM-B1020
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T, L/C
Supply Ability :
5 Sets / Month
Delivery Time :
30 working days
Packaging Details :
wooden pallet
Model NO. :
FM-B1220
Structure :
Unit Type
Application :
Flexible Packaging Printing
Automatic Grade :
Automatic
Printing Speed :
150m/Min
Max. Web Width :
920mm
Max. Printing Width :
900mm
Max. Die-Cutting Width :
900mm
Printing Repeat :
286-1200mm
Die-Cutting Repeat :
286-1200mm
Max. Unwinder Diameter :
1524mm/1200mm
Max. Rewinder Diameter :
1524mm/1200mm
Gearing :
1/8cp
Max. Printing Speed :
150m/Min
Diameter of Web Roller :
100mm
Transport Package :
Wooden Pallets with Film Package
Specification :
CE
Trademark :
FENGMING
Origin :
Zhejiang, China
HS Code :
8443160090
Printing Page :
Single Faced
Printing Color :
4 Colors
Anilox Roller :
Ceramic Anilox Roller
Dryer :
UV& IR
Type :
Ink Jet
Embossing Structure :
Rotary Letterpress
Customization :
Available | Customized Request
Description

Single Faced Printing Page Carton Board Materials Flexo Printing Machine FM-B1220

We are Flexo Press!


FM-B920 Flexo Printing Machine
Single Faced Printing Page Carton Board Materials Flexo Printing Machine FM-B1220



Application Object:

Suitable for eco-friendly packaging such as paper cup, paper box, pre-printing carton for food/housing, milk package and wall paper printing etc.

Paper used:

Kraft paper, carton board material, coated paper, liner paper, laminated paper, wall paper, nonwoven etc.

Medium-Range Flexographic Press
Specification 35.5"(900) 39.5"(1000) 47.5"(1200)
Max. web width 920mm 1020mm 1220mm
Max. printing width 900mm 1000mm 1200mm
Printing repeat 286-1200mm
Max. printing speed 150m/min
Max. unwinder/rewinder diameter 1524mm/1200mm
Drying mode a. warm drying b. IR drying c. UV drying
Ink used Water-based ink or UV ink
Power supply 3 phase 380V 50Hz
Suitable material Light weight coated paper, carton board materials, kraft paper, chrome paper, PVC wall paper, laminated paper, white cardboard paper, aluminium-foil paper


Wide-Range Flexographic Press
Specification 50.4"(1330) 56.5"(1430) 64.2"(1630) 72.0"(1830)
Max. web width 1350mm 1450mm 1650mm 1850mm
Max. printing width 1330mm 1430mm 1630mm 1830mm
Printing repeat 600-1600mm
Max. printing speed 150m/min
Max. unwinder /
rewinder diameter		 1524mm
Drying mode a. warm drying b. IR drying c. UV drying
Ink used Water-based ink or UV ink
Power supply 3 phase 380V 50Hz
Suitable material Light weight coated paper, carton board materials, kraft paper, chrome paper, PVC wall paper, laminated paper, white cardboard paper, aluminium-foil paper

Main characteristics:

1. Capable of inline cleaning dust, printing, and cutting
2. Eco-friendly printing, water based ink and UV ink used
3. Metal anilox rollers can be used for a long time, and can supply ink appropriately.
4. Warm drying, IR drying, UV drying are available
5. Closed loop tension control is used to make printing tension much more stable , and register much more accurate.
6. Automatically electronic web-guide system
7. Online printing register detection
8.Register system can be operated automatically or by manual.

Our service:

Top quality, competitive price, timely del;ivery and heart-to-heart service.

Delivery: About 60 days after receiving 30% deposit by T/T.

Warrantee: One year guarantee, life-long maintence.

FAQ


1, Q: How about the after service?
A: We have a strong team, special for after service. We can arrange engineers to do service for you.

2, Q: Are you factory or trading company?
A: Professional manufacturer of flexo printing machine. We are definitely factory.

3, Q: Where is your factory located? How can I visit there?
A:Our factory is located in Pingyang Wenzhou City, Zhejiang Province, China, near to the Wenzhou airport. You can fly to Wenzhou airport directly.

4, Q:How does your factory do regarding quality control?
A:Quality is priority. We always attach great importance to quality controlling from the very beginning.

5, Q: why choose Fengming Machinery?
A: Our qualified products and service have enabled us to expand our market from China to more than 40 countries. We are confident that you will be satisfied with our machines.

Welcome to visit Fengming Machinery!
