Specifications
Brand Name :
FENGMING
Model Number :
FM-A650
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T, L/C
Supply Ability :
10 Sets / Month
Delivery Time :
30 working days
Packaging Details :
wooden pallet
Model NO. :
FM-A650-1320
Application :
Flexible Packaging Printing
Automatic Grade :
Automatic
Printing Speed :
150m/mim
Max. Web Width :
650/920/1020/1220/1320mm
Max. Printing Width :
600/900/1000/1200/1270mm
Printing Repeat Length :
286-1200mm
Max. Unwinder & Rewinder Diameter :
1524mm
Gearing :
1/8cp
Max. Speed :
150m/Min
Diameter of Web Roller :
100mm
Main Motor Power Supply :
11kw
Drying Mode :
Hot Air Drying & IR Drying
Ink Used :
Water Based Ink
Power Supply :
380V 3pH 50Hz
Printing Material :
60-350GSM Paper Roll
Transport Package :
Wooden Pallet with Film Package
Specification :
1020mm
Trademark :
Fengming
Origin :
Zhejiang, China
HS Code :
8443160090
Printing Page :
Single Faced
Printing Color :
2 Colors
Anilox Roller :
Ceramic Anilox Roller
Dryer :
UV& IR
Embossing Structure :
Rotary Letterpress
Structure :
Unit Type
Customization :
Available | Customized Request
Description

Fengming's Unit Type Structure FM-A650-1320 Flexo Press Printing Machine for Printing

Fengming's Unit Type Structure FM-A650-1320 Flexo Press Printing Machine for Printing
Fengming's Unit Type Structure FM-A650-1320 Flexo Press Printing Machine for Printing
FM-650-920-1320 Flexographic Printing Machine

Application Object

Suitable for eco-friendly packaging, such as the paper bag used for food and healthcare industry, paper box, paper cup, the pre-printing carton of paper bag, bag courier, milk carton medicine use.

Paper Used

Kraft paper, paperboard, coated paper, liner paper, laminated paper, multilayer composite paper, carton board materials ect.

Technical Parameters:
Specification 650 920 1020 1220 1320
Max. Web Width 650mm 920mm 1020mm 1220mm 1320mm
Max. Printing Width 600mm 900mm 1000mm 1200mm 1300mm
Max Die-Cutting Width 600mm 900mm 1000mm 1200mm 1300mm
Printing Repeat 286-1200mm 286-1200mm 286-1200mm 286-1200mm 286-1200mm
Max.Unwinder Diameter 1524mm 1524mm 1524mm 1524mm
Max.Rewinder Diameter 1524mm 1524mm 1524mm 1524mm 1524mm
Gearing 1/8cp 1/8cp 1/8cp 1/8cp 1/8cp
Max Printing Speed 150m/min 150m/min 150m/min 150m/min 150m/min
Diameter of web roller 100mm 100mm 100mm 100mm 100mm
Drying mode Warm Drying/IR Drying/ UV Drying (optional)
Oil used Water based ink/ UV Ink
Power Requirement 380V 3PH 50Hz
Substrate 17g copy paper, cotton paper, 80-400g art paper, aluminum-foil paper, paper board, kraft paper

Fengming's Unit Type Structure FM-A650-1320 Flexo Press Printing Machine for Printing
Fengming's Unit Type Structure FM-A650-1320 Flexo Press Printing Machine for Printing
Fengming's Unit Type Structure FM-A650-1320 Flexo Press Printing Machine for Printing
Fengming's Unit Type Structure FM-A650-1320 Flexo Press Printing Machine for Printing
