Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Specifications
Brand Name :
FENGMING
Model Number :
FM-B1020
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T, L/C
Supply Ability :
50 Sets/Year
Delivery Time :
30 working days
Packaging Details :
wooden pallet
Model NO. :
FM-B
Structure :
Unit Type
Application :
Pre Printed Carton
Automatic Grade :
Automatic
Printing Speed :
150m/mim
Color :
up to Customers
Printing Width :
Max. 1830mm
Max. Rewinder Diameter :
1524mm
Max. Printing Speed :
150m/Min
Printing Repeat :
286-1200mm
Transport Package :
Wooden Case with Package
Specification :
CE ISO9001
Trademark :
Fengming
Origin :
Zhejiang, China
HS Code :
8443160090
Printing Page :
Single Faced
Printing Color :
Multicolors
Anilox Roller :
Ceramic Anilox Roller
Dryer :
UV& IR
Type :
Ink Jet
Embossing Structure :
Rotary Letterpress
Customization :
Available | Customized Request
Description

Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed


We are Flexo Press!

Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed


Max. 1830mm High Speed Flexo Printing Machine for Paper Carton 150m/mim Printing Speed
Multicolors High Speed Flexographic Printing Machine
Application:
High Speed Flexo Printing Machine is a flexo printing machine which adopts flexible photosensitive resin plates,rubber plates as the base material, anilox rollers for transferring ink,liquid ink for printing. It is controlled centrally by PLC system and generally consists of unwinding section, infeed section,printing section, drying section, outfeed section, rewinding section and control section.This machine is an ideal machine for printing paper cup, carton, paper bag, paper package, and so on.
Medium-Range Flexographic Press

Specification35.5"(900)39.5"(1000)47.5"(1200)
Max. web width920mm1020mm1220mm
Max. printing width900mm1000mm1200mm
Printing repeat 286-1200mm
Max. printing speed 150m/min
Max. unwinder/rewinder diameter 1524mm/1200mm
Drying mode a. warm drying b. IR drying c. UV drying
Ink used Water-based ink or UV ink
Power supply 3 phase 380V 50Hz
Suitable material Light weight coated paper, carton board materials, kraft paper, chrome paper, PVC wall paper, laminated paper, white cardboard paper, aluminium-foil paper

Wide-Range Flexographic Press
Specification 50.4"(1330) 56.5"(1430) 64.2"(1630) 72.0"(1830)
Max. web width 1350mm 1450mm 1650mm 1850mm
Max. printing width 1330mm 1430mm 1630mm 1830mm
Printing repeat 600-1600mm
Max. printing speed 150m/min
Max. unwinder /
rewinder diameter		 1524mm
Drying mode a. warm drying b. IR drying c. UV drying
Ink used Water-based ink or UV ink
Power supply 3 phase 380V 50Hz
Suitable material 17g copy paper, cotton paper, 40-450g paper, aluminium-foil paper, BOPP, PET, paper board, kraft paper

Main characteristics:
1. Capable of inline cleaning dust, printing, and cutting
2. Eco-friendly printing, water based ink and UV ink used
3. Metal anilox rollers can be used for a long time, and can supply ink appropriately.
4. Warm drying, IR drying, UV drying are available
5. Closed loop tension control is used to make printing tension much more stable , and register much more accurate.
6. Automatically electronic web-guide system
7. Online printing register detection
8.Register system can be operated automatically or by manual.
Our service:
Top quality, competitive price, timely delivery.
Delivery: About 60 days after receiving 30% deposit by T/T.
Warrantee: One year guarantee, life-long maintence.
