1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
Specifications
Brand Name :
haijing
Model Number :
HJ-1500
Certification :
CE
Place of Origin :
RUIAN
MOQ :
1 set
Price :
5
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
9999 PCS per minute
Delivery Time :
15
Packaging Details :
wooden case
Type :
Slitting Rewinder,Paper Cutting Machine,paper slitting machine,hot stamping foil cutter,Laminating Machine
Dimension(l*w*h) :
2150*2600*1400mm(L*W*H)
Condition :
NEW
Voltage :
220V/380V
Weight :
3.5T
Warranty :
2 Years
Computerized :
Yes
After-sales service provided :
Engineers available to service machinery overseas
Power(w) :
3.7KW
Product name :
paper slitting machine,slitter rewinder machine paper roll cutting/slitting machine,label slitting and rewinding machine,Fabric label bopp tape thermal paper slitting machine price,SG-H500 paper creasing machinery/paper creasing
Speed :
110 m/min
Color :
as customer's requirements,Silver
Function :
Slitting Rewinding JUMBO Paper Roll,Slitting Rewinder
Machine type :
precise slitting rewinder,Slitter Material With Small Roll,Small Paper Making Machine
Cutting speed :
500 m/min
Rewind core diameter :
22mm - Option
Slitting width :
Adjustable Width Maximum 900mm
Power :
Electricity
Description

Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone Paper

1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone

1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper converting machine Paper Slit Machine for Craft Paper Silicone Paper

The slitting rewinding machine is mainly used to slit sticker paper, craft paper, silicone paper, coated paper and other kinds of paper in width range of 1600mm-3000mm.

1. Material to slit:

Recycled paper, Kraft paper, Paperboard, With and without print.

Weight (gr/m²): 40-500 g/m2

2. Mother roll (Unwinder rolls)

Width: 1600 mm-3000mm

Chucks Core: 3, 4, 6, 12inches

Max diameter: 1500 mm or max. 2100mm

Max Weight: 4000kg or more

3. Rewind roll (Output rolls)

Air shaft Core: 3, 4 or 6inches

Max diameter: 1200 mm-1600mm

4. Slitting size: Min width: 100 mm

Knfifeholders: Normal circular slitting knife or Pneumatic circular knife (can be chosen)

5. Working Speed: 600 m/min

6. Features:

Unwinder shaftless, pneumatic brake controlled (Motor controlled as optional).

Guide system electromechanical

Bowed roller (Banana roller) with hydraulic controlled

Paper Edge blowing system

Rewinder 2 drum rollers with 2 motors

Automatic ejector for finished rolls

Hydraulic unloading system for finished rolls and loading at ground level.

Main parameters:

Jumbo roll width 1600-3000mm
Diameter of roll Ø1500mm-2100mm
Diameter of rewinding Ø1200mm-1600mm
Inner dia.of paper core 3'', 6''
Slitting speed 10-600m/min
Tolerance of EPC ≤0.1mm
Min.width of produce 100mm
Weight 17000Kg


Optional:

1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
1, Pneumatic circular knife


2, Unwinder 2 pneumatic brakes change to 2 Motors+2 inverters + reducers and loadcell for auto tension controlled.


3, Automatic pneumatic knife moving system


4, extra air shafts for rewinder, 3inch, 4inch, 6inch

1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone

1600/3000 Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine Paper Slit Machine for Craft Paper Silicone
