HJ-400 Adjustable Roll Feeding V Bottom Paper Bag Making Machine use water cold glue and yaskawa servo system ce

Environmental Protection Efficent Intelligent ,The HJ-400 Adjustable Roll Feeding V Bottom Paper Bag Making Machine use water cold glue and yaskawa servo system ce is made from rolls of unprinted kraft paper rolls or printing rolls such as kraft paper rolls ,striped kraft paper ;oil-gloss paper ;food coated paper and other paper materials .The bag making process is from rolls of paper to folding ;forming ,cutting ,gluing ;bottom folding and make paper bag output at one time .This model is more convenient to operate ,more efficient and more stable .It is an ideal equipment for producing various shopping bags ,snack food bags ,bread bags ,dried fruit bags and other environmentally friendly paper bags

1. Material loading and unloading adopts pneumatic lifting structure

2.Automatic constant tension control system ,the tension is not bad from beginning to the end

3.Accurate color code tracking system ,automatic shutdown for color code errors

4.Photoelectric sensor limit ,automatic correction control system ,stable correction ,energy saving and long life

5.Ultra-precison servo motor control system ensures stable and efficient operation of the machine

6.Using the touch screen man machine interface,real time work status is realized ,that can be set by the touch screen man machine interface

Technical Parameter:

Paper Bag Length is 120-420mm

Paper Bag Width is 80-240mm

Paper Thickness 30-80 gsm

Machine speed is 60-400 pcs /minute

Paper roll width 260-720mm

Insert paper edge : 20-100mm

Machine power : 6 kw

Machine weight 1800kgs

Machine Size 4400 x1700 x1600mm

PE coating paper rolls

Food paper bag

Bread paper bags

two sides gusset paper bag

kfc hamburger paper bag

Kraft paper rolls paper bag making machine
