Specifications
Brand Name :
haijing
Model Number :
HJ-1500
Certification :
CE
Place of Origin :
RUIAN
MOQ :
1 SET
Price :
7
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
88
Delivery Time :
15
Packaging Details :
WOODEN CASE
Automatic grade :
Automatic
Type :
4 color flexo nylon flour bag printing machine/paper bag printer
Usage :
Paper Printer
Weight :
3000kgs 3500kgs 4000kgs
Dimensions(l*w*h) :
4.8m*3.2m*2.8m
Description

4 Color Alumnium Foil Flexo Printing Machine High Speed 4 Colors Flexo Printing Machine, 200m/min

4 Color Flexographic Printing Machine

Application:
This machine is suitable for printing such packing materials as polyethylene, polyethylene plastic bag, glass paper ,and roll paper etc. And it is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.

Product Parameters

Feature:


1. The frame adopts 75MM thick wall, full casting flat plate, increase the scale and so on to enhance the stability.
2. The printing roller is made of thickened steel bars, with 10 silk thick hard chrome protective layer.
3. The aluminum alloy guide wheel, with hard oxidation, dynamic balance, static balance treatment.
4. High-precision wider synchronous belt drive, low noise while high speed running, low vibration, makes machine more stable.
5.The plate roller gear, adopts special helical gear transmission. Each tooth 5MM, more stable printing effect, and more accurate printing length .

Main points:

-Adopts the synchronous belt drive instead of Gear drive;
-Machine running more quite, higher printing precision, good quality;
-Machine more stability;
-High Mechanical speed: 135m/min
-High printing speed: 30-120m/min ( match chamber doctor blade)
-Single unwind & Single rewind

Model 600 4-800 4-1000 4-1200 4-1400 4-1600
Max. Material width 650mm 850mm 1050mm 1250mm 1450mm 1650mm
Max. Printing width 560mm 760mm 960mm 1160mm 1360mm 1560mm
Printing color 4+0,3+1,2+2
Printing length 11.8''-35.4''(300-900mm)/11.8''-47.2''(300-1200mm)
Printing cylinder way Hydraulic control up and down
Drive type Synchronous belt drive
Mechanical speed 135m/min
Printing speed 10-90m/min
Anilox roller (1) Metal anilox roller 4pcs:100-300LPI
(2) Ceramic anilox roller 4pcs: Shanghai murata brand 200-800LPI
Open type doctor blade 4pcs
Tension system Automatic tension controller with magnetic powder brake and clutch
EPC Web guide 1pcs
Register precision Longitudinal:±0.2mm crosswise:±0.2mm;
Color register By manual
Unwind/rewind dia. Φ1000mm/Φ1200mm/Φ1500mm
Material holder Air shaft 3'', 2pcs
Dry system Electric heating
Machine power 24kw 26kw 28kw 30kw 34kw 36kw
Machine size
(L x W x H)		 5.6×2×3m 5.6×2.2×3m 5.6×2.4×3m 5.6×2.6×3m 5.6×2.8×3m 5.6×3m×3m
Machine weight 4500Kg 4800 Kg 5000 Kg 5200 Kg 5400 Kg 5600 Kg
Detailed Photos

4 Color Alumnium Foil Flexo Printing Machine, High Speed 200m/min,4 color flexo nylon flour bag printing machine/paper4 Color Alumnium Foil Flexo Printing Machine, High Speed 200m/min,4 color flexo nylon flour bag printing machine/paper4 Color Alumnium Foil Flexo Printing Machine, High Speed 200m/min,4 color flexo nylon flour bag printing machine/paper4 Color Alumnium Foil Flexo Printing Machine, High Speed 200m/min,4 color flexo nylon flour bag printing machine/paper4 Color Alumnium Foil Flexo Printing Machine, High Speed 200m/min,4 color flexo nylon flour bag printing machine/paper4 Color Alumnium Foil Flexo Printing Machine, High Speed 200m/min,4 color flexo nylon flour bag printing machine/paper4 Color Alumnium Foil Flexo Printing Machine, High Speed 200m/min,4 color flexo nylon flour bag printing machine/paper
