High Speed Semi-Automatic Corrugate Carboard Box Stitching Machine

The main parts and function of BDJ-2000 type high speed semi-automatic nail box machine:

★ imported from Japan fujiseries double servo drive, precision, reduce the mechanical transmission part, effectively reduce the mechanical fault rate.

★ Delta touch screen operation, the parameters (screw pitch, the number of nails, nail, tailgate) transform is convenient.

★ the whole control system adopts the control system of delta PLC, more accurately convey instructions.

★ after electric baffle, by Taiwan Liming stepper motor drive, accurate size, transform size more convenient.

★ the bottom die, tungsten steel blade adopts Japanese made (wear) has greatly increased the service life.

★ The whole group of nail head. All computer gongs are made of special steel, precision machining, imported from Taiwan, Italy.

★ You can nail a single nail, double nail, once completed, can be suitable for different customers for different requirements for the nail.

★ This transformation and adjustment of carton size from the nail it takes only a minute to be completed, greatly saves time and is convenient to operate.

★ the front feeding part automatically counting, the feeding table is provided with a photoelectric sensing device, automatic rising feeder.

★ This post with automatic counting function, finished cartons can be set according to the number (1-99) sub stack sent to lose

Send machine end, easy to pack up and bound.

★ Nail automatic alarm after line. (to avoid the non linear when the leak to fight, less nail bad product)

★ from semi-finished stapled to the finished and packaged Banding placed in the whole process of only two people operation, the operation is simple and convenient for less pay.

Mechanical parameters:

Mechanical model BDJ-2000 maximum paper size 1515 x 2460mm

Machine speed 600 nails / min minimum paper size 300 x 606mm

The total horsepower of the 30-100mm (adjustable) 6HP

The number of nails to the paper height 900mm 1-99

Single screw, double screw machine size long 2800mm width 2600mm

Pin line size 2.0mm x (0.65 to 0.75mm) mechanical weight 2000KGS
