Specifications
Brand Name :
LS
Model Number :
YTB
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20set/month
Delivery Time :
Within 30 working days
Packaging Details :
film packing or wooden packing, wooden packing is with additional fee
Price :
USD15000-50000
print color :
1. 2. 4. 6. 8
print width :
600 mm 800 mm 1000 mm 1200mm 1400mm 1600mm
plate thickness :
2.28 mm 3.9 mm 1.7 mm
material type :
drum rolling type
transmission :
gear or belt
Description

Unwind / Rewind Unit Flexographic Printing Machine for Both Side Roll plastic/ Roll Paper

High speed stack type Flexographic Printing Machine for Both Side Roll paper, plastic film PP woven sack non woven fabr
Specifications:

Model

YTB41000mm

Max. print material width

10 20mm

Printing width

9 60mm

Printing material

Paper: 50 ~ 150g/m2

Printing color

6 color (6+0)

Printing length

7.5"~ 5 0"(190mm~1 5 00mm)

Mechanical speed

100m/min

Printing speed

10m- 80m/min

Register precision

Longitude:±0.25mm Transverse:±0.25mm

Rewinder/Unwinder DIA

Φ 1000mm (unwinding)
Φ 1000mm (rewinding)

Printing plate lifting system

Auto Hydraulic cylinder control printing roll up and down

EPC system:

Edge Position Controller, 1 PC

Tension system

Automatic tension control for unwinding 1 PCS

Unwinding loading and rewinding unloading way

By air shaft , with 10 kg magnetic 2 pcs
With 1.5 kw motor compages rewinding

Printing Pressure

M echanical adjust

Anilxo roll

Standard metal anilxo roll (1 0 0-300PLI)
Or
High: ceramic anilox roller ( 3 00-800lpi), single doctor

blade

Master motor

3.7Kw TAIWAN BRAND

Drying way

Electrical heat drying

Drying power

24 kw

Blower of nature wind

0.95 Kw x 6 pcs
75W x 12 pcs

Inking motor

Taiwan brand

Master frequency converter

3.7 kw

Master power

32 Kw

Dimension(L×W×H)

5.4 ×2. 4× 3.2 m

Application:

PE Film Printing Machine for Plastic Packag

Super-Thin Material Printing Machine

4 Colors Serviette Flexographic Printing Machine

PP Woven Bag Flexo Printing Machine

Colorful Woven Bag Flexo Printing Machine

Auto Multi-Colors Flexo Printer

High Speed Six Color Non Woven Bag Flexographic Printing Machine


Competitive Advantage

1. Low speed and full load startup; stable running by tension control when increasing and decreasing speed;noise is decreased

2. Aluminum roller adopts the Japan semi-sealing small bearing; flinty oxidation, static and dynamic balancing treatments are conducted; low resistance and small flop.

3. The special made modulus angular gears adopted; accurate printing size and full printing specifications
( 6.35mm is a spec)

4. With single doctor blade and circulating pump

5. The grouped and controlled bottom roller processed with Germany particular steel materials processed with special techniques and electrically gilded with 0.1mm hard chromium protective layers

6. With hard chroming anilox roll

7. The machine use hydraulic printing-roll loading system which can automatically load printing rolls and run inks after the machine alarm working signal.

8. Good quality printing

9. Brilliance color appearance.

10. The operation is easier and more convenient,the register is more accurate,and the lifespan is also longer


Printing Effect :
High speed stack type Flexographic Printing Machine for Both Side Roll paper, plastic film PP woven sack non woven fabrHigh speed stack type Flexographic Printing Machine for Both Side Roll paper, plastic film PP woven sack non woven fabrHigh speed stack type Flexographic Printing Machine for Both Side Roll paper, plastic film PP woven sack non woven fabrHigh speed stack type Flexographic Printing Machine for Both Side Roll paper, plastic film PP woven sack non woven fabr

High speed stack type Flexographic Printing Machine for Both Side Roll paper, plastic film PP woven sack non woven fabrHigh speed stack type Flexographic Printing Machine for Both Side Roll paper, plastic film PP woven sack non woven fabrHigh speed stack type Flexographic Printing Machine for Both Side Roll paper, plastic film PP woven sack non woven fabr
