Non Woven Automatic Flexographic Printing Machine with Multi Color
Non Woven Automatic Flexographic Printing Machine with Multi Color
Non Woven Automatic Flexographic Printing Machine with Multi Color
Non Woven Automatic Flexographic Printing Machine with Multi Color
Non Woven Automatic Flexographic Printing Machine with Multi Color
Non Woven Automatic Flexographic Printing Machine with Multi Color
Non Woven Automatic Flexographic Printing Machine with Multi Color
Non Woven Automatic Flexographic Printing Machine with Multi Color
Specifications
Brand Name :
LS
Model Number :
YTB
Certification :
CE
Place of Origin :
China
MOQ :
1set
Payment Terms :
L/C, T/T
Supply Ability :
20set/month
Delivery Time :
30days before deposite
Packaging Details :
wooden pallte
print color :
1. 2. 4 . 6 .8
print width :
600mm 800mm 1000mm
print speed :
80m/min
machine speed :
100m/min
Description

Non Woven Automatic Flexographic Printing Machine with Multi Color

use

Company is mainly engaged in design and manufacturing of printing machines. It is capable of

independently developing new flexographic printing machines.

If need any video or data about our machine, pls contact Elaine ,phone :+8613780130609(whats APP)

The main features:

1. Take it easy, accurate color, long life.
2. Use motors, variable frequency speed control, saving electricity, small running fluctuations.
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink.
4. Use special diagonal-tooth gear, accurate printing size.
5. Two sets of heating devices, including central heating and constant temperature control system for

group control.
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective

layer of hard chromium.
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced.
8 With cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. Print produce are clear and good arrangement quality.
10. Bearing: NSK, Japan Brand, Germany ASNU aluminum alloy roll

Model

YTB 1000mm

Max. print material width

10 50mm

Printing width

9 60mm

Printing material

Paper: 50 ~ 35 0g/m2

Printing color

6 color (6+0)

Printing length

7.5"~ 5 0"(190mm~1 5 00mm)

M e ch a nical speed

9 0m/min

Printing speed

1 0m- 7 0m/min ( if you need high speed machine, pls

contact Linda 0086-18857728175)

Register precision

Longitude:±0.25mm Transverse:±0.25mm

Rewinder/Unwinder DIA

Φ 12 00mm (unwinding)
Φ 13 00mm (rewinding)

Printing plate lifting system

Auto Hydraulic cylinder control printing roll up and

down

EPC system:

Edge Position Controller, 1 PC

Tension system

Automatic tension control for unwinding 1 PCS

Unwinding loading and rewinding unloading way

By air shaft , with 10 kg magnetic 2 pcs
With 1.5 kw motor compages rewinding

Printing Pressure

M echanical adjust

Anilxo roll

Standard metal anilxo roll (1 0 0-300PLI)
Or
High: ceramic anilox roller ( 3 00-800lpi), single doctor

blade

Master motor

3.7Kw TAIWAN BRAND

Drying way

Electrical heat drying

Drying power

24 kw

Blower of nature wind

0.95 Kw x 6 pcs
75W x 12 pcs

Inking motor

Taiwan brand

Master frequency converter

3.7 kw

Master power

32 Kw

Dimension(L×W×H)

5.4 ×2. 4× 3.2 m

Sample :

Non Woven Automatic Flexographic Printing Machine with Multi Color
