Plastic Processed PE extrusion blow molding machine For Polypropylene , Double Layer
Plastic Processed PE extrusion blow molding machine For Polypropylene , Double Layer
Plastic Processed PE extrusion blow molding machine For Polypropylene , Double Layer
Plastic Processed PE extrusion blow molding machine For Polypropylene , Double Layer
Plastic Processed PE extrusion blow molding machine For Polypropylene , Double Layer
Plastic Processed PE extrusion blow molding machine For Polypropylene , Double Layer
Specifications
Brand Name :
LS
Model Number :
2SJ
Certification :
CE
Place of Origin :
CHINA
MOQ :
one set
Delivery Time :
Within 30 working days
Packaging Details :
Wooden packing
Blow Moulding Type :
Extrusion Blow Moulding
Max. Output :
80kg/h
Screw Ratio L/D :
28:1
Plastic Processed :
PE
Single-face Thickness of film (mm) :
0.015-0.10
After-sales Service Provided :
Engineers available to service machinery overseas
Warranty :
one year
Description

Plastic Processed PE extrusion blow molding machine For Polypropylene , Double Layer


Quick Detail:

Condition: New
Blow Moulding Type: Extrusion Blow Moulding
Application: Film
Automatic: Yes
Screw Ratio L/D : 28:1
Max. Output : 80kg/h
Plastic Processed: PE
Single-face Thickness of film (mm) : 0.015-0.10
Warranty: one year
After-sales Service Provided: Engineers available to service machinery overseas


Description:


1. Double-layer co-extrusion laminated film can prolong the length for preservation of liquid package.

2. The cylinder and the screw stem of the extruder are made of high quality alloy steel with optimum hardness and durable service after precision finishing and nitrogen treatment.
3. The auxiliary machine has a platform working table for making operation easy and is equipped with bubble stabilizing ring.
4. Double-rolling and double-cutting coiling unit adopts torque motor to keep proper tensions and make rolling even and roll- changing easy.


Specifications:

Model

2SJ-G50

2SJ-G55

2SJ-G60

Diameter of screw

Φ50×2

Φ55×2

Φ60×2

L/D

28:1

28:1

28:1

Reduced diameter of film(mm)

800

1000

1200

Single-face Thickness of film(mm)

0.015-0.10

0.015-0.10

0.015-0.10

Max. Output(kg/h)

40

65

80

Power of main motor(kw)

11×2

15×2

18.5×2

Heating Power(kw)

26

30

42

Outline diameter(L×W×H)(mm)

4200×2200×4000

4600×2400×4600

5000×2800×5000

Weight(T)

4

5

6



Application:
It is used for blowing the plastic laminated film of low density polyethylene (LDPE), high density polythylene(HDPE)and linear low density polyethylene(LLDPE)etc,Which are widely used for packing liquid, printed base material, products for export and industrial products,etc.

Product Sample:

Plastic Processed PE extrusion blow molding machine For Polypropylene , Double Layer
