3 PC Side Entry Floating Ball Valves Peek Seat Welded Body Design
3 PC Side Entry Floating Ball Valves Peek Seat Welded Body Design
Specifications
Brand Name :
VERVO
Model Number :
Q41F-150LB
Certification :
API/CE/ISO
Place of Origin :
LISHUI,ZHEJIANG
MOQ :
10
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, D/A
Supply Ability :
40000pcs/month
Delivery Time :
1 week
Packaging Details :
plywood case
Name :
2 piece Ball Valve
Standard :
API608/Gost/Din
Pressure :
Class 150 to Class 2500
Temperature Of Media :
Medium Temperature,Normal Temperature,High Temperature-29℃ To 120℃)
Size :
Sizes NPS 2 to NPS 8
Seat Material :
PTFE,RPTFE,Devlon,Nylon,Peek
Connection :
Thread BSP NPT,Female Thread/OD Size,threaded,Female,RF,RTJ,SW
Description
Floating Ball Valve

VERVO floating ball valves are offered in 2 PC side entry, 3 PC side entry or welded body design in a wide range of carbon, stainless steel, duplex stainless steel, alloy and other special materials. VERVO floating ball valves are manufactured according to API 6D or API 608 Design and fire tested per API 6FA and API 607 Standard.

PRODUCT RANGE

Sizes NPS 2 to NPS 8

Class 150 to Class 2500

MATERIALS

Available Forging (A105, A182 F304, F3304L, F316, F316L, A182 F51, F53, A350 LF2, LF3, LF5) Casting (A216 WCB, A351 CF3, CF8, CF3M, CF8M, A352 LCB, LCC, LC2, A995 4A. 5A), Inconel, Hastelloy, Monel
DESIGN FEATURES
Full or Reduced Bore

RF, RTJ, or BW

Bolted bonnet or welded body design

Anti-Static Device

Anti-Blow out Stem

Cryogenic or High Temperature, Extended Stem

DESIGN STANDARD

Design & manufacture according to API 6D, API 608, ISO 17292

Face-to-face according to API 6D, ASME B16.10 OR MFG’s standard

End Connection according to ASME B16.5 (RF & RTJ), ASME B16.25 (BW)

Test & inspection according to API 6D, API 598

Fire safe design according to API 6FA, API 607

Also available per NACE MR-0175, NACE MR-0103, ISO 15848

Keywords of VERVO floating ball valves are offered in 2 PC side entry, 3 PC side entry or welded body design in a wide range of carbon, stainless steel, duplex stainless steel, alloy and other special materials.

3 PC Side Entry Floating Ball Valves Peek Seat Welded Body Design

A216 WCB Floating Ball Valve, Floating Ball Valve, PN25 Ball Valve, 1 1/4 Inch Ball Valve, RF Ball Valve,1.25 Inch Ball Valve,Soft Seated Ball Valve,Soft Ball Valve,Metal to Metal Seat
