Specifications
Brand Name :
HONWAY
Model Number :
HW-G1
Certification :
CE SGS ISO9001
Place of Origin :
China
MOQ :
1Set/Sets
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability :
100Set / Sets month
Delivery Time :
7 Working days
Packaging Details :
High Density Polyethylene pallet; Conform to export standard.
Voltage :
220V 1phrase
Power output :
2.2kw 3hp
Motor brand :
50/60HZ
Current :
13A
Grinding width :
280mm / 11”
Grinding pressure :
41KG / 90.2lbs
Net Weight :
75KG / 165lbs
Additional Weight :
N / A
Dast port :
∅ 50mm
Motor speed :
1440rmp
Description

Small Area Concrete Floor Grinding Machine Ergonomic Working Posture 220V 1 Phrase

Application

Concrete floor preparation

Concrete grinding & surface leveling

Horizontal floor surface preparation

Concrete floor repairing

Video:

Parameters

Model HW-G1
Voltage: 220V 1phrase
Power output: 2.2KW,3hp
Motor Brand: China Winder
Frequency: 50/60HZ
Current: 13A
Grinding Width: 280mm/11”
Grinding Pressure: 41KG/90.2lbs
Additional Weight: N/A
Dust Port: Φ50mm
Motor Speed: 1400rmp
Diamond Pad Holder: 6 Pieces
Machine L*W*H: 1100*420*1000mm
Net Weight: 75KG/165lbs

Advantages

Grinding floor edge;

Grinding small area,

Floating cover for dust free

Very easy for transportation and set-up;

Ergonomic working posture

Quick change of diamond pad, no need for tools;

Easy for machine maintenance

Closer Look

Small Area Concrete Floor Grinding Machine Ergonomic Working Posture 220V 1 Phrase

Small Area Concrete Floor Grinding Machine Ergonomic Working Posture 220V 1 Phrase

Company Introduction

Small Area Concrete Floor Grinding Machine Ergonomic Working Posture 220V 1 Phrase

After Sell Service

  1. One year of warranty for machine.
  2. We always supply the consumables.
  3. We always supply the spare parts for all the old models.
  4. The spare parts can be sent out immediately at any time, delivered by DHL.
  5. The CD and operation manual is sent with machine to guide the installation process works and repair problems.
  6. All machines are tested, and the testing record will be kept, before it leaves factory.
  7. If the customers visit our factory, we could provide the training lessons.

FAQ

Q: If the floor edge grinder could grind floor?

A: Yes, it can; its grinding width is 280mm and its grinding pressure is 90.2 lbs;

Q: If HW-G1 could grind floor edge and leaves no margin at all?

A: G1 could grind floor edge, but leaves margin of 2mm, which is the narrowest margin which the floor edge grinder could achieve. It is impossible for any machine to leave margin 0mm.

Q: If HW-G1 could grind right edge and left edge?

A: Yes. It can; the two sides could grind floor edge;

Q: How about the floating cover of HW-G1?

A: The floating cover follow floor up and down, preventing dust from entering work site.
